Jinma 654B
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Jinma 654B is a tractor from Jinma. The four-cylinder engine produces 48 kW. Rated speed is 2,300 rpm.
Drive type: MFWD.
The engine is water-cooled. Within the range, rated power spans from 11.8 to 92 kW; with 48 kW, the 654B sits in the upper third. Directly alongside are the 654A with 47.8 kW below and the 724 with 54 kW above.
Technical data
Engine
| Engine model | YTR4105T63correct |
|---|---|
| Power | 65 hp (48 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Cylinders | 4correct |
| Bore | 105 mmcorrect |
| Stroke | 125 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Wheelbase | 2,236 mmcorrect |
|---|
Drivetrain and chassis
| Drive | selectable four-wheel drivecorrect |
|---|
Working data
| PTO speed | 540/720correct |
|---|
Origin and approval
| Plant | Chinacorrect |
|---|
Frequently asked questions
How much power does the Jinma 654B have?
The Jinma 654B delivers 65 hp.
What engine does the Jinma 654B have?
4 cylinders.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 14 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Other models in this series
Sources: [1]
Tractor in 3D section
Turn the model, look inside and click an assembly — each one is explained.
