Jinma 654A
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Jinma 654A is a tractor from Jinma. The four-cylinder engine produces 47.8 kW. Rated speed is 2,300 rpm.
It runs with MFWD.
The engine is water-cooled. Within the range, rated power spans from 11.8 to 92 kW; with 47.8 kW, the 654A sits in the mid-field. Directly alongside are the 624 with 45.6 kW below and the 654B with 48 kW above.
Technical data
Engine
| Engine model | YTR4105T62correct |
|---|---|
| Power | 65 hp (47.8 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Cylinders | 4correct |
| Bore | 105 mmcorrect |
| Stroke | 110 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Wheelbase | 2,060 mmcorrect |
|---|
Drivetrain and chassis
| Drive | selectable four-wheel drivecorrect |
|---|
Working data
| PTO speed | 540/720(1000)correct |
|---|
Origin and approval
| Plant | Chinacorrect |
|---|
Frequently asked questions
How much power does the Jinma 654A have?
The Jinma 654A delivers 65 hp.
What engine does the Jinma 654A have?
4 cylinders.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
