Jinma 1204
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Jinma 1204 is a tractor made by Jinma. It is powered by a six-cylinder engine producing 88.2 kW. Rated power is reached at 2,400 rpm.
It runs with MFWD.
The engine is water-cooled. Within the range, rated power spans from 11.8 to 92 kW; with 88.2 kW, the 1204 sits at the top. Directly alongside are the 1004B with 73.5 kW below and the 1254 with 92 kW above.
Technical data
Engine
| Engine model | LRC6108T79correct |
|---|---|
| Power | 120 hp (88.2 kW)correct |
| Rated speed | 2,400 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 7.41correct |
| Bore | 108 mmcorrect |
| Stroke | 135 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Wheelbase | 2,689 mmcorrect |
|---|
Drivetrain and chassis
| Drive | selectable four-wheel drivecorrect |
|---|---|
| Forward gears | 12correct |
| Reverse gears | 4correct |
| Clutch | Dual stagecorrect |
Working data
| Lifting capacity | 26,000correct |
|---|---|
| Linkage category | Cat IIcorrect |
Frequently asked questions
How much power does the Jinma 1204 have?
The Jinma 1204 delivers 120 hp.
What engine does the Jinma 1204 have?
6 cylinders.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
