JCB Fastrac 7200

Built: 2008 · Series: Fastrac

More machines from model year 2008

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Fastrac series from JCB includes the Fastrac 7200. Production: 2008. The engine delivers 200 hp (150 kW). The engine comes from Cummins. The engine is water-cooled. The model was built in England. The fuel is diesel. The Fastrac series covers 29 models. Rated output within it ranges from 185 to 260 hp; the Fastrac 7200 sits in the lower part of that range with 200 hp. Its immediate neighbours are the FASTRAC 3200-80 below it with 193 hp and the Fastrac 3220 above it with 220 hp. 788 JCB models across 59 series are on record.

JCB Fastrac – Fully Suspended High-Speed Tractor Since the Early 1990s: six-cylinder diesels with 105.9 to 250 kW (185 to 260 hp), top speed up to 70 km/h

JCB introduced the Fastrac in the early 1990s as the first fully suspended agricultural tractor, capable of significantly higher road speeds than conventional tractors. The models recorded in the register travel at 51.5 to 70 km/h, which also makes the Fastrac attractive for road haulage duties.

Read on 3 more paragraphs

The six-cylinder engines produce between 105.9 and 250 kW, with models rated in horsepower spanning 185 to 260 hp, at a displacement of 5,883 to 8,419 cm³. Recorded operating weight runs from 6,260 to 12,847 kg, and lift capacity of the recorded models reaches up to 10,000 kg.

A defining feature of the series is its four equal-size wheels combined with hydro-pneumatic suspension on both axles, giving the Fastrac a smoother ride than conventional tractors both in the field and on the road. JCB positions the range for farms and contractors with heavy transport demands. Buyers of a used unit should check the condition of the suspension components, which require more service attention than on unsprung tractors.

With a lift capacity of up to 10,000 kg and operating weights above 12 tonnes, the largest Fastrac models use a category III three-point hitch under ISO 730, otherwise needed only by heavy field tractors and self-propelled harvesters. The PTO is two-speed, at 540 and 1,000 rpm. The full suspension requires regular checks of the hydro-pneumatic cylinders and seals, which are under greater strain at the high travel speeds than on conventional tractors.

Sources: SpecCodex register, model data: JCB Fastrac, JCB

Technical data

Engine

Engine makeCumminscorrect
Fueldieselcorrect
Power200 hp (150 kW)correct
Coolingwater-cooledcorrect

Drivetrain and chassis

Drivefour-wheel driveWDcorrect

Origin and approval

PlantEnglandcorrect

Frequently asked questions

How much power does the JCB Fastrac 7200 have?

The JCB Fastrac 7200 delivers 200 hp.

When was the JCB Fastrac 7200 built?

Production years: 2008.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
