JCB 412S

Series: JCB Wheel Loader

Source: https://commons.wikimedia.org/w/index.php?curid=164331951 u

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the 412S, JCB offers a model from the JCB Wheel Loader series. The engine delivers 164.6 hp (110.1 kW), has 4 cylinders, with a displacement of 4,401.6 cm³. Torque is 434.1 Nm. Rated speed is 2,200 rpm. The wheelbase measures 2,700.5 mm. Ground clearance is 402.3 mm. The tank holds 125.3 litres. The gearbox has 6 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 54.1 l/min. The hydraulic tank holds 110.2 litres. The cooling system holds 21.6 litres. The electrical system runs on 24 V. Tyre size: 17,5LR24 XM27. The JCB Wheel Loader series covers 64 models. Rated output within it ranges from 36.5 to 261.6 hp; the 412S sits in the middle of that range with 164.6 hp. Its immediate neighbours are the 456ZX below it with 163.2 hp and the 419S HT HL above it with 175.4 hp. 752 JCB models across 38 series are on record. The model is listed under Wheel loaders. 20 verified figures from 1 source are on file.

Technical data

Engine

Power164.6 hp (110.1 kW)correct
Rated speed2,200 rpmcorrect
Torque434.1correct
Speed at max. torque1,400 rpmcorrect
Cylinders4correct
Displacement4,401.6 cm³correct
Aspirationturbochargedcorrect
Coolant capacity21.6 lcorrect

Dimensions and weights

Wheelbase2,700.5correct
Ground clearance402.3correct

Drivetrain and chassis

Gearbox typesmooth shift powershift transmissioncorrect
Forward gears6correct
Reverse gears3correct
Tyre size17.5LR24 XM27correct
System voltage24 Vcorrect

Working data

Pump flow54.1 l/mincorrect
Hydraulic oil capacity110.2 lcorrect
Fuel tank capacity125.3 lcorrect

Other data

Height2,831.6correct

Frequently asked questions

How much power does the JCB 412S have?

The JCB 412S delivers 165 hp.

What engine does the JCB 412S have?

4 cylinders, 4,402 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
