JCB 403 AGRI

Series: JCB Wheel Loader

Source: https://www.technikboerse.com/gebraucht/radlader-255/jcb-590

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The JCB 403 AGRI belongs to the JCB Wheel Loader series. The engine delivers 36.5 hp (26.8 kW), has 4 cylinders, with a displacement of 1,499.4 cm³. The engine comes from Kubota. Rated speed is 2,700 rpm. The unladen weight is 2,507 kg. The wheelbase measures 1,600.2 mm. Ground clearance is 243.8 mm. The tank holds 48.1 litres. Maximum torque is reached at 2,200 rpm. The pump delivers 40.5 l/min. The hydraulic tank holds 40.1 litres. The cooling system holds 6.8 litres. The engine fitted is the V1505. The JCB Wheel Loader series covers 64 models. Rated output within it ranges from 36.5 to 261.6 hp; the 403 AGRI sits at the bottom of that range with 36.5 hp. Its immediate neighbours are the 406 above it with 49.7 hp. 752 JCB models across 38 series are on record. The model is listed under Wheel loaders. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine makeKubotacorrect
Engine modelV1505correct
Power36.5 hp (26.8 kW)correct
Rated speed2,700 rpmcorrect
Speed at max. torque2,200 rpmcorrect
Cylinders4correct
Displacement1,499.4 cm³correct
Aspirationnaturally aspiratedcorrect
Coolant capacity6.8 lcorrect

Dimensions and weights

Wheelbase1,600.2correct
Ground clearance243.8correct
Unladen weight2,507 kgcorrect

Drivetrain and chassis

Gearbox typeZF / Bosch-Rexrothcorrect

Working data

Pump flow40.5 l/mincorrect
Hydraulic oil capacity40.1 lcorrect
Fuel tank capacity48.1 lcorrect

Other data

Height2,200.7correct

Where this model stands

Power-to-weight ratio: 10.7 kW/t (27 kW / 2.5 t)

Stronger than 2% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the JCB 403 AGRI have?

The JCB 403 AGRI delivers 36.5 hp.

How much does the JCB 403 AGRI weigh?

The unladen weight is 2,507 kg.

What engine does the JCB 403 AGRI have?

4 cylinders, 1,499 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
