JCB 411BHT

Series: JCB Wheel Loader

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The JCB Wheel Loader series from JCB includes the 411BHT. The engine delivers 91.2 hp (59.7 kW), has 4 cylinders, with a displacement of 3,990.3 cm³. Torque is 325.1 Nm. Rated speed is 2,200 rpm. The wheelbase measures 2,700.5 mm. Ground clearance is 411.5 mm. The tank holds 125.3 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 50.7 l/min. The hydraulic tank holds 110.2 litres. The cooling system holds 21.6 litres. The electrical system runs on 12 V. The engine fitted is the 1004-4TLR2. Tyre size: 15,5x25x12 SGL. The JCB Wheel Loader series covers 64 models. Rated output within it ranges from 36.5 to 261.6 hp; the 411BHT sits in the lower part of that range with 91.2 hp. Its immediate neighbours are the 411ZX Zet below it with 87.2 hp and the 416HT Super High Lift above it with 91.8 hp. 752 JCB models across 38 series are on record. The model is listed under Wheel loaders. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine model1004-4TLR2correct
Power91.2 hp (59.7 kW)correct
Rated speed2,200 rpmcorrect
Torque325.1correct
Speed at max. torque1,400 rpmcorrect
Cylinders4correct
Displacement3,990.3 cm³correct
Aspirationturbochargedcorrect
Coolant capacity21.6 lcorrect

Dimensions and weights

Wheelbase2,700.5correct
Ground clearance411.5correct

Drivetrain and chassis

Gearbox typesemi automatic gearbox full powershift transmissioncorrect
Forward gears4correct
Reverse gears3correct
Tyre size15.5x25x12 SGLcorrect
System voltage12 Vcorrect

Working data

Pump flow50.7 l/mincorrect
Hydraulic oil capacity110.2 lcorrect
Fuel tank capacity125.3 lcorrect

Other data

Height3,014.5correct

Frequently asked questions

How much power does the JCB 411BHT have?

The JCB 411BHT delivers 91.2 hp.

What engine does the JCB 411BHT have?

4 cylinders, 3,990 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
