Hyundai R210LC-7A – specifications
Series: Hyundai Hydraulic Excavator
The Hyundai R210LC-7A belongs to the Hyundai Hydraulic Excavator series. The engine delivers 153.1 hp (106.6 kW), with a displacement of 6,702.3 cm³. Torque is 618.3 Nm. The unladen weight is 21,681.7 kg. Ground clearance is 481.6 mm. The tank holds 340.3 litres. The pump delivers 219.9 l/min. The hydraulic tank holds 290.3 litres. Working pressure is 323.4 bar. The cooling system holds 35.2 litres. The oil fill is 24.2 litres. The electrical system runs on 24 V. The engine fitted is the QSB6,7. The Hyundai Hydraulic Excavator series covers 56 models. Rated output within it ranges from 95.3 to 517.1 hp; the R210LC-7A sits at the bottom of that range with 153.1 hp. Its immediate neighbours are the R210NLC-7 below it with 152.1 hp and the R220LC-9A above it with 169.3 hp. Unladen weight within it ranges from 11,200 to 82,320 kg; here the R210LC-7A sits at the bottom of that range with 21,681.7 kg. 428 Hyundai models across 28 series are on record.
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hyundai R series: LC, D, and the -7/-7A generation tag behind the number
Hyundai's excavator lineup consistently starts with the prefix R, followed by a number for the size class and usually a letter code for the undercarriage type. LC stands for a lengthened, widened crawler track ("Long Crawler") that increases ground contact area and improves stability on soft or uneven terrain — bucket models such as R140LC-7, R160LC-7 and R180LC-7 carry this code.
Read on 3 more paragraphs
The D suffix, by contrast, marks a wheeled excavator instead of a crawler machine, as seen in this bucket's R110D-7. After the number comes the generation tag: the digit 7 marks a particular excavator generation, and the trailing A on models like R450-7A, per an industry source, denotes adaptation to a stricter emissions standard within the same generation.
The "Hyundai Hydraulic Excavator" bucket spans smaller site machines like the R110-7 up to heavyweights like the R450-7A, and across its 56 active models covers 62 to 365 kW of engine power, 11,200 to 82,320 kg operating weight, 4- to 6-cylinder engines, and torque from 371 to 2364 Nm.
Buying used, LC models are worth checking for wider track shoes and pads, which wear unevenly under intensive digging, along with the seals on the dipper and boom cylinders.
Sources: SpecCodex register, model data: Hyundai Hydraulic Excavator, CM-SV: What Do the Letters of Each Brand and Model of Excavator Mean, Machineryline: Overview of Hyundai R Series Excavators
Technical data
Engine
| Engine model | QSB6.7correct |
|---|---|
| Power | 153.1 hp (106.6 kW)correct |
| Torque | 618.3 Nmcorrect |
| Displacement | 6,702.3 cm³correct |
| Aspiration | Turbocharged and Charge air cooledcorrect |
| Coolant capacity | 35.2 lcorrect |
| Engine oil capacity | 24.2 lcorrect |
Dimensions and weights
| Ground clearance | 481.6 mmcorrect |
|---|---|
| Unladen weight | 21,681.7 kgcorrect |
Working data
| Pump flow | 219.9 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 290.3 lcorrect |
| Hydraulic pressure | 323.4 barcorrect |
| Fuel tank capacity | 340.3 lcorrect |
Other data
| Cab height | 2,923 mmcorrect |
|---|---|
| System voltage | 24 Vcorrect |
Frequently asked questions
Area: Machines › Construction machinery
More machines with this engine (Cummins QSB6.7, 69)
Where this model stands
Power-to-weight ratio: 4.9 kW/t (107 kW / 21.7 t)
Stronger than 45% of the excavators & compaction in the register — out of 1,650 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 16 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Are you the manufacturer or a dealer of this machine? Check the data and add missing figures — we mark your correction as manufacturer or dealer information.
Check and complete the data →Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
