Hyundai HSL680T

Series: Hyundai Skid Steer Loader

Source: https://www.hyundai.com/pl/pl/modele/nowa-kona-electric/desi

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Hyundai Skid Steer Loader series from Hyundai includes the HSL680T. The engine delivers 50.7 hp (34.3 kW). Rated speed is 2,800 rpm. The wheelbase measures 890 mm. Ground clearance is 191 mm. Top speed is 9.8 km/h. The tank holds 64.4 litres. The pump delivers 62.8 l/min. The hydraulic tank holds 30.7 litres. Working pressure is 165.5 bar. The engine fitted is the V2203T. Tyre size: 10,00x16,5. The Hyundai Skid Steer Loader series covers 15 models. Rated output within it ranges from 20.1 to 88.6 hp; the HSL680T sits in the middle of that range with 50.7 hp. Its immediate neighbours are the HSL650-7 below it with 44.8 hp and the HSL800T above it with 60.3 hp. 391 Hyundai models across 22 series are on record. The model is listed under Wheel loaders. 13 verified figures from 1 source are on file.

Technical data

Engine

Engine modelV2203Tcorrect
Power50.7 hp (34.3 kW)correct
Rated speed2,800 rpmcorrect

Dimensions and weights

Wheelbase890correct
Ground clearance191correct

Drivetrain and chassis

Tyre size10.00x16.5correct
Top speed9.8 km/hcorrect

Working data

Pump flow62.8 l/mincorrect
Hydraulic oil capacity30.7 lcorrect
Hydraulic pressure165.5correct
Fuel tank capacity64.4 lcorrect

Other data

Height1,868.4correct

Frequently asked questions

How much power does the Hyundai HSL680T have?

The Hyundai HSL680T delivers 50.7 hp.

How fast does the Hyundai HSL680T go?

Top speed is 9.8 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 13 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
