Hyundai HSL610

Series: Hyundai Skid Steer Loader

Source: https://cn.baupool.com/details/%E7%A7%BB%E5%8A%A8%E6%8C%96%E

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the HSL610, Hyundai offers a model from the Hyundai Skid Steer Loader series. The engine delivers 42 hp (30.1 kW). Rated speed is 2,500 rpm. The wheelbase measures 917.4 mm. Ground clearance is 183.1 mm. Top speed is 10.6 km/h. The tank holds 58.7 litres. The pump delivers 61.3 l/min. The hydraulic tank holds 37.1 litres. Working pressure is 168.2 bar. The engine fitted is the 4TNE88. Tyre size: 10-16,5. The Hyundai Skid Steer Loader series covers 15 models. Rated output within it ranges from 20.1 to 88.6 hp; the HSL610 sits in the lower part of that range with 42 hp. Its immediate neighbours are the HSL500T below it with 33.5 hp and the HSL600T above it with 43.6 hp. 391 Hyundai models across 22 series are on record. The model is listed under Wheel loaders. 13 verified figures from 1 source are on file.

Technical data

Engine

Engine model4TNE88correct
Power42 hp (30.1 kW)correct
Rated speed2,500 rpmcorrect

Dimensions and weights

Wheelbase917.4correct
Ground clearance183.1correct

Drivetrain and chassis

Tyre size10-16.5correct
Top speed10.6 km/hcorrect

Working data

Pump flow61.3 l/mincorrect
Hydraulic oil capacity37.1 lcorrect
Hydraulic pressure168.2correct
Fuel tank capacity58.7 lcorrect

Other data

Cab height1,956.8correct

Frequently asked questions

How much power does the Hyundai HSL610 have?

The Hyundai HSL610 delivers 42 hp.

How fast does the Hyundai HSL610 go?

Top speed is 10.6 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
