Hyundai HSL500T

Series: Hyundai Skid Steer Loader

Source: https://www.landwirt.com/baumaschinen/radlader/hyundai/land-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Hyundai HSL500T belongs to the Hyundai Skid Steer Loader series. The engine delivers 33.5 hp (22.5 kW). Rated speed is 3,000 rpm. The wheelbase measures 847.3 mm. Ground clearance is 178.1 mm. Top speed is 9.3 km/h. The tank holds 43.2 litres. The pump delivers 33.3 l/min. The hydraulic tank holds 34.1 litres. Working pressure is 148.2 bar. The engine fitted is the V1305B. Tyre size: 10,5x15. The Hyundai Skid Steer Loader series covers 15 models. Rated output within it ranges from 20.1 to 88.6 hp; the HSL500T sits in the lower part of that range with 33.5 hp. Its immediate neighbours are the HSL275T below it with 25.3 hp and the HSL610 above it with 42 hp. 391 Hyundai models across 22 series are on record. The model is listed under Wheel loaders. 13 verified figures from 1 source are on file.

Technical data

Engine

Engine modelV1305Bcorrect
Power33.5 hp (22.5 kW)correct
Rated speed3,000 rpmcorrect

Dimensions and weights

Wheelbase847.3correct
Ground clearance178.1correct

Drivetrain and chassis

Tyre size10.5x15correct
Top speed9.3 km/hcorrect

Working data

Pump flow33.3 l/mincorrect
Hydraulic oil capacity34.1 lcorrect
Hydraulic pressure148.2correct
Fuel tank capacity43.2 lcorrect

Other data

Height1,804.4correct

Frequently asked questions

How much power does the Hyundai HSL500T have?

The Hyundai HSL500T delivers 33.5 hp.

How fast does the Hyundai HSL500T go?

Top speed is 9.3 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 13 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
