Hydro Connect HC-EGBP5037
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hydro Connect – other models: the collective page of MEPS-registered three-phase motors outside the named ranges, frame sizes 100 to 115, 2.2 to 3.7 kW, two-pole, IP56 protection
This page gathers the Hydro Connect three-phase motors the Australian energy-efficiency register could not assign to a named range. The designations recorded in the register, HC-EGBP5022 and HC-EGBP5037, follow the maker's own scheme of a company code and a multi-digit sequence; exactly how the digits are to be read cannot be reconstructed from the dump alone.
Read on 3 more paragraphs
The register lists here 2 versions with 2.2 to 3.7 kW rated output, both two-pole, for a 380 to 415 V supply, with full-load efficiencies from 86.75 to 87.92% and at 75% load from 85.44 to 87.84%. Protection is IP56, frame sizes run from 100 to 115, the mounting code is B3 (foot type). Manufacturing takes place in China, testing followed the 2019 GEMS determination with test method B.
Two-pole three-phase motors of this power class run at a synchronous speed of 3,000 rpm at 50 Hz and are chiefly used in high-speed pumps and compressors; the IP56 rating – dust-tight and protected against powerful water jets from all sides – allows, unlike the simpler IP44 class, use in unsheltered outdoor settings too.
When buying used, bearing condition and a checked insulation resistance of the winding, the tightness of the terminal box and shaft lead-through, the condition of shaft and key, and a legible nameplate with frame size, pole count and protection rating matter. Spares run through Hydro Connect's distribution.
Sources: SpecCodex register, model data: Hydro Connect (weitere Modelle, MEPS-Registrierungen)
Technical data
Engine
| Rated output | 3.7 kWcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP56correct |
| Frame size | 115 (flange)correct |
| Mounting (IEC 60034-7) | B3correct |
| Efficiency at full load | 87.92 %correct |
| Efficiency at 75 % load | 87.84 %correct |
| Efficiency at half load | 86.05 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | IEC 61972correct |
Frequently asked questions
How much power does the Hydro Connect HC-EGBP5037 have?
The Hydro Connect HC-EGBP5037 delivers 3.7 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 20 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
