Hürlimann H-20
Built: 1950–1951 · Series: H-Reihe
More machines from model year 1950
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hürlimann H-Reihe – four-cylinder petrol field tractors from Wil, Switzerland: types H-10 to H-20, 2,060 to 4,020 cm³ displacement, 19.1 to 33.1 kW, unladen weights of 1,440 to 1,660 kg
Hürlimann, the Swiss tractor works headquartered in Wil in the canton of St. Gallen, founded by Hans Hürlimann, lists the H range in the register with the types H-10, H-12, H-17 and H-20. The type numbers traditionally followed Hürlimann's approximate power class of the engine; the H range was fitted throughout with four-cylinder petrol engines, at a time when diesel engines were not yet universally standard in Swiss agricultural machinery.
Read on 3 more paragraphs
The register lists 4 versions with 19.1 to 33.1 kW from four-cylinder engines throughout, of 2,060 to 4,020 cm³ displacement, unladen weights from 1,440 to 1,660 kg and rated speeds from 1,400 to 1,700 rpm; lengths range from 2,660 to 2,760 mm, widths from 1,490 to 1,585 mm, heights from 1,460 to 1,480 mm.
Hürlimann's H-range tractors supplied Swiss farms in hilly and mountainous terrain, where compact dimensions and a low centre of gravity gave an advantage over larger field tractors, competing with other Swiss and southern German makers of small tractors.
On a used Hürlimann H-range tractor, the condition of the petrol engine's carburettor and ignition system, rust on the frame and mudguards, the tightness of the gearbox and axles, and the function of the brakes and steering after decades of use all count; because production has ended, parts are mostly only available within enthusiast and collector circles.
Sources: SpecCodex register, model data: Hürlimann H-Reihe
Technical data
Engine
| Fuel | Benzin/Petrolcorrect |
|---|---|
| Power | 32 hp (23.5 kW)correct |
| Rated speed | 1,450 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,020 cm³correct |
| Bore | 100 mmcorrect |
| Stroke | 128 mmcorrect |
| Compression ratio | 17correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 2,760 mmcorrect |
|---|---|
| Width | 1,490 mmcorrect |
| Height | 1,480 mmcorrect |
| Wheelbase | 1,730 mmcorrect |
| Unladen weight | 1,660 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 5V/1Rcorrect |
| Forward gears | 5correct |
| Reverse gears | 1correct |
| Front tyres | 6.00 x 15"correct |
| Rear tyres | 11.25 x 20"correct |
| Top speed | 20 km/hcorrect |
Working data
| Fuel tank capacity | 36 lcorrect |
|---|
Origin and approval
| Units built | 167correct |
|---|
Where this model stands
Power-to-weight ratio: 14.2 kW/t (24 kW / 1.7 t)
Power class: Compact (< 40 hp)
Stronger than 19% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Hürlimann H-20 have?
The Hürlimann H-20 delivers 32 hp.
How much does the Hürlimann H-20 weigh?
The unladen weight is 1,660 kg.
What engine does the Hürlimann H-20 have?
4 cylinders, 4,020 cm³ displacement, Benzin/Petrol.
How fast does the Hürlimann H-20 go?
Top speed is 20 km/h.
What are the dimensions of the Hürlimann H-20?
2,760 mm × 1,490 mm × 1,480 mm.
When was the Hürlimann H-20 built?
Production years: 1950–1951.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
