Heinrich Lanz D 1506
Lata produkcji: 1937–1955 · Seria: HR 8
Dane techniczne
| Construction | Blockbauweise |
| Cooling | Wasser |
| Cylinders | 1 |
| Displacement cm3 | 10338 cm3 |
| Drive type | Hinterradantrieb |
| Fuel | Vielstoff |
| Gearbox | 6V/2R |
| Ground clearance mm | 260 mm |
| Height mm | 2185 mm |
| Length mm | 3455 mm |
| Power km | 55 KM |
| Power kw | 40.3 kW |
| Rated rpm | 750 obr./min |
| Tires front | 7.00-20 |
| Tires rear | 12.75-28 |
| Top speed kmh | 20 km/h |
| Weight kg | 3950 kg |
| Wheelbase mm | 2036 mm |
| Width mm | 1780 mm |
Inne modele tej serii
Źródła: [1]
