Heinrich Lanz D 7506 (18.3 kW) – specifications
Built: 1935–1942 · Series: HN 3
The Heinrich Lanz D 7506 belongs to the HN 3 series. Production: 1935–1942. The engine delivers 25 hp (18.3 kW), has 1 cylinder, with a displacement of 4,767 cm³. The machine is 2,845 mm long, 1,598 mm wide and 2,025 mm high. The unladen weight is 2,800 kg. The wheelbase measures 1,683 mm. Ground clearance is 270 mm. Top speed is 15.2 km/h. Transmission: 6V/2R. The engine is water-cooled. Tyres: front 7.00-20, rear 11.25-24. The fuel is Vielstoff. Construction: unit construction (no separate frame). Around 13.397 units were built. The HN 3 series covers 6 models. 89 Heinrich Lanz models across 27 series are on record.
Data for the version built 1935–1942 · Data origin: Reference work (Wikipedia/Wikibooks) · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Heinrich Lanz HN 3 - the Bulldog with a hot-bulb single cylinder: D 7500 to D 7531, 4.8-litre displacement, 18.3 kW at 760 to 850 rpm, multi-fuel operation
Since 1921, the Lanz Bulldog had epitomised the slow-running hot-bulb single-cylinder engine: a horizontal two-stroke with a pre-chamber whose hot bulb was heated with a blowlamp before starting and which then sustained combustion without spark ignition. The HN 3 series, with types D 7500 to D 7531, belongs to this Bulldog family, built by Heinrich Lanz in Mannheim; the four-digit number after the D distinguishes the individual versions of the series.
Read on 3 more paragraphs
The register lists 6 versions with a uniform 18.3 kW from the single-cylinder engine of 4,767 cm³, kerb weights of 1,980 to 3,240 kg, lengths of 2,735 to 2,935 mm, widths of 1,524 to 1,700 mm and heights of 1,785 to 2,030 mm at speeds of 760 to 850 rpm; every model runs as a multi-fuel engine.
The low-revving hot-bulb engine made the Bulldog a multi-fuel unit that, besides diesel, could also burn crude oil, tar oil and other hard-to-ignite fuels - a decisive advantage in regions without a reliable diesel supply, which made the Bulldog an export success worldwide. Its characteristic, far-carrying slow chugging at low revs shaped the sound of agriculture for decades.
On a used example with a hot-bulb engine, check the condition of the hot bulb and pre-chamber, compression, the cooling-water circuit and crankshaft bearings of the long-stroke single cylinder, and the clutch and gearbox; given the age of this series, original parts are scarce and repair work mostly lies in the hands of Lanz Bulldog specialists and vintage-vehicle clubs.
Sources: SpecCodex register, model data: Heinrich Lanz HN 3
Versions of this model in the register
Each row is a separate entry with its own data. The figures on this page belong to the row marked ●.
| Version | Built | kW | EU type approval | Origin |
|---|---|---|---|---|
| D 7506 | 1934–1935 | 14.6 | — | Reference work (Wikipedia/Wikibooks) |
| ● D 7506 | 1935–1942 | 18.3 | — | Reference work (Wikipedia/Wikibooks) |
Technical data
Engine
| Fuel | Vielstoffcorrect |
|---|---|
| Power | 25 hp (18.3 kW)correct |
| Rated speed | 760/850 rpmcorrect |
| Cylinders | 1correct |
| Displacement | 4,767 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 2,845 mmcorrect |
|---|---|
| Width | 1,598 mmcorrect |
| Height | 2,025 mmcorrect |
| Wheelbase | 1,683 mmcorrect |
| Ground clearance | 270 mmcorrect |
| Unladen weight | 2,800 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 6V/2Rcorrect |
| Front tyres | 7.00-20correct |
| Rear tyres | 11.25-24correct |
| Top speed | 15.2 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|---|
| Units built | 13,397correct |
Frequently asked questions
Where this model stands
Power-to-weight ratio: 6.5 kW/t (18 kW / 2.8 t)
Power class: Compact (< 40 hp)
Stronger than 12% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
