Haulotte HA12IP – specifications
Series: Haulotte Boom Lift
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Haulotte HA12IP is an electrically powered aerial work platform from the manufacturer's boom lift series. As a model designated "HA," it belongs to the group of articulating boom lifts, characterized by their compact design and specific boom geometry. The machine is designed for use indoors or on sensitive surfaces, which is reflected in the choice of drive system and tires.
With a working height of 12,000 mm and a platform capacity of 230 kg, the HA12IP is designed for elevated work involving a single operator and tools. The empty weight of 5,910 kg requires attention to permissible axle loads during transport, while the ground clearance of 140.2 mm allows the machine to overcome obstacles such as cable ducts or uneven surfaces. The dimensions of 5,430 mm in length and 1,340 mm in width enable maneuvering in narrow aisles, supported by a turning radius of 2,850 mm. The solid, non-marking tires in size 23x10x12 prevent floor contamination, which is crucial in warehouses or production facilities. The maximum speed of 4.5 km/h is designed for safe positioning drives.
In comparison within the series, the HA12IP ranks 38th out of 49 models in terms of empty weight. The next smaller model, the HA12PX, weighs 5,640 kg, while the next larger model, the H14TX, weighs 6,040 kg. The weight of the HA12IP is practically identical to that of the HB 40 and HA33 JE models. The total weight range of the series extends from 645 kg to 23,904.3 kg.
Haulotte Boom Lifts: What TX, TPX and TJ Actually Mean
Models like the H14 TX, H16 TPX or H28 TJ carry an "H" for telescopic boom lift, a number, and a suffix. Comparing the manufacturer's own datasheets shows the H14 TX reaches a working height of 14.07 m and the H16 TPX 15.44 m — so the number roughly tracks working height in metres.
Read on 4 more paragraphs
The key difference between TX and TPX sits in the boom tip: per the datasheet, the H16 TPX adds a pivoting jib with ±70° of vertical movement that the H14 TX simply doesn't have. Models carrying a "J" in the name, like the H28 TJ, likewise carry such a jib for fine basket positioning. Articulating models marked "HA", such as the HA16X, use a knuckle boom instead of pure telescoping.
Platform capacity stays constant across the category: both recorded values in the SpecCodex data sit at 230 kg, matching the manufacturer's own figure for the H14 TX/H16 TPX line.
When buying used, check the jib joint's condition, hydraulic hoses running inside the telescoping sections, the 4WD and differential-lock function, and hours on the clock. Since recorded weight spans from 645 kg to 23.9 tonnes, always confirm the exact model before ordering parts.
In short: the number is a rough working height, while TX/TPX/TJ describe the boom tip and terrain equipment.
Sources: SpecCodex register, model data: Haulotte Boom Lift, — Haulotte: Datenblatt H14 TX / H16 TPX, — Haulotte France: Gamme nacelles télescopiques
Technical data
Engine
| Drive type | electriccorrect |
|---|
Dimensions and weights
| Length | 5,430 mmcorrect |
|---|---|
| Width | 1,340 mmcorrect |
| Ground clearance | 140.2 mmcorrect |
| Unladen weight | 5,910 kgcorrect |
| Platform length | 1,200.1 mmcorrect |
| Platform width | 800.1 mmcorrect |
Drivetrain and chassis
| Tyre size | 23x10x12correct |
|---|---|
| Tyre type | solid/non markingcorrect |
| Top speed | 4.5 km/hcorrect |
| Turning radius | 2,850 mmcorrect |
Working data
| Lifting capacity | 230 kgcorrect |
|---|---|
| Working height | 12,000 mmcorrect |
| Hydraulic oil capacity | 30.3 lcorrect |
| Platform capacity | 230 kgcorrect |
Electrical data
| Battery capacity | 360 Ahcorrect |
|---|---|
| Number of batteries | 6correct |
Other data
| System voltage | 48 Vcorrect |
|---|
Used listings – figures from public listings
Between May and November 2026, speccodex recorded 11 public used-machine listings for Haulotte HA12IP on 3 platforms. Asking prices ranged from €8,500 to €24,000 (median €10,900), years of manufacture between 2003 and 2020.
Offered mainly in Germany (100%); shares refer to listings that state a location.
Asking prices are sellers' demands, not achieved sale prices. Basis: public listings, recorded and analysed by speccodex. As of: 15 Nov 2026. Sellers usually do not state whether prices are net or gross.
Area: Machines › Construction machinery
Frequently asked questions
How much does the Haulotte HA12IP weigh?
The unladen weight is 5,910 kg.
What are the dimensions of the Haulotte HA12IP?
5,430 mm × 1,340 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
