Hanomag WD Kleinpflug
Built: 1921–1924 · Series: WD
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hanomag WD – agricultural tractors from Hanover with four-cylinder engines of 4,252 to 5,700 cc, multi-fuel and petrol versions, 19 to 26 kW
The Hanomag WD range, like the brand's other agricultural tractors, came from the Hannoversche Maschinenbau AG plant in Hanover. The register lists the WD Kleinpflug here, along with the types WD R 26 and WD R 28/32, which differ in engine size and chassis layout. A notable feature of the range is its drivetrain technology: alongside straightforward petrol engines, Hanomag also fitted the WD range with multi-fuel engines that could run on different fuels, a practical advantage during the post-war period of scarce and fluctuating fuel supply.
Read on 3 more paragraphs
The register lists 3 versions here with 19 to 26 kW from four-cylinder engines of 4,252 to 5,700 cc, kerb weights of 1,950 to 3,200 kg, a length of 3,130 mm, a width of 1,600 mm and a height of 1,500 mm; two of the engines are of multi-fuel design, one is petrol.
The WD range covered the middle power segment in West Germany's post-war farming, and with its robust technology geared towards fuel flexibility it competed with Deutz and Lanz tractors of the same class found on farms at the same time.
When buying a used WD model, the key points are the condition and tightness of the particular engine, as the multi-fuel and petrol versions bring different carburettor or ignition technology, plus the condition of clutch and gearbox, steering and front axle, and corrosion on the chassis and panels; spare parts are now only stocked by dealers specialising in vintage machinery.
Sources: SpecCodex register, model data: Hanomag WD
Technical data
Engine
| Fuel | Mehrstoffcorrect |
|---|---|
| Power | 35 hp (26 kW)correct |
| Cylinders | 4correct |
| Displacement | 5,700 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Unladen weight | 3,200 kgcorrect |
|---|
Drivetrain and chassis
| Drive | Vorderachsantriebcorrect |
|---|---|
| Gearbox | 2 vorwärts, 1 rückwärtscorrect |
| Front tyres | Eisen mit verstellbaren Spatengreiferncorrect |
| Top speed | 6 km/hcorrect |
Origin and approval
| Construction | Tragpflugcorrect |
|---|
Where this model stands
Power-to-weight ratio: 8.1 kW/t (26 kW / 3.2 t)
Power class: Compact (< 40 hp)
Stronger than 21% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Hanomag WD Kleinpflug have?
The Hanomag WD Kleinpflug delivers 35 hp.
How much does the Hanomag WD Kleinpflug weigh?
The unladen weight is 3,200 kg.
What engine does the Hanomag WD Kleinpflug have?
4 cylinders, 5,700 cm³ displacement, Mehrstoff.
How fast does the Hanomag WD Kleinpflug go?
Top speed is 6 km/h.
When was the Hanomag WD Kleinpflug built?
Production years: 1921–1924.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
