Griffioen
Built: 2024-2025 · Series: Other models
More machines from model year 2024
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Griffioen – other models: the collective page of trailers outside the named ranges, from G 1250 to G 4200 DZW and GR 3500 LV, 720 to 11,940 kg kerb weight, 1,250 to 16,800 kg gross weight
This page gathers the Griffioen trailers the register could not assign to a named range. Griffioen is a Dutch manufacturer of trailers and low-loader semi-trailers. The G type designation combines the range with a four-digit number matching the gross weight in kilograms – from G 1250 to G 4200 – supplemented by the suffixes EL, KHR, LR, ZHS or DZW for equipment; the model name AHW 16.8 uses the Dutch abbreviation AHW for aanhangwagen, meaning trailer.
Read on 3 more paragraphs
The register lists 28 versions here with a kerb weight of 720 to 11,940 kg and a gross weight of 1,250 to 16,800 kg, at lengths of 4,420 to 14,900 mm and widths of 1,600 to 2,640 mm.
The spread from just over 1 t to nearly 17 t gross weight shows the brand's wide range between single-axle transport trailers and multi-axle low-loaders for construction machinery and plant. Griffioen thus serves both smaller agricultural and service businesses and construction firms and hire companies that need heavier trailers for machine transport.
Buying a used lighter Griffioen trailer means checking the load bed, side panels and overrun brake; on the heavier low-loaders, also check the frame and welds for cracks, the axle units, the braking system and, on hydraulically lowered models, the tightness and operation of the hydraulics. Tyres, wheel bearings and lighting belong in the basic check on every version. Parts are available through the Dutch commercial-vehicle accessory trade and through the manufacturer.
Sources: SpecCodex register, model data: Griffioen (weitere Modelle), Zulassungsdaten RDW (Niederlande)
Technical data
Dimensions and weights
| Length | 6,590 mmcorrect |
|---|---|
| Width | 2,380 mmcorrect |
| Wheelbase | 3,920 mmcorrect |
| Unladen weight | 2,120 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|---|
| Top speed | 140 km/hcorrect |
Frequently asked questions
How much does the Griffioen GRIFFIOEN weigh?
The unladen weight is 2,120 kg.
What is the gross vehicle weight of the Griffioen GRIFFIOEN?
3,500 kg.
Up to what speed is the Griffioen GRIFFIOEN approved?
Approved up to 140 km/h.
What are the dimensions of the Griffioen GRIFFIOEN?
6,590 mm × 2,380 mm.
When was the Griffioen GRIFFIOEN built?
Production years: 2024-2025.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 9 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
