Gbr Holder GmbH & Co E300B / E300D
Built: 1980–19XX · Series: E-Reihe
More machines from model year 1980
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Holder E300B/E300D: air-cooled single-cylinder compact tractor in block construction with 3-speed gearbox, 6.6 kW and only 75 kg weight, from 1980
Holder was a German maker of small single-axle and compact tractors based in Baden-Württemberg, building machines for commercial horticulture, viticulture and grounds maintenance. The E series comprised particularly light, single-axle small tractors offered in petrol or diesel form; the B designation stands for the petrol engine, D for the diesel.
Read on 3 more paragraphs
The E300B/E300D is powered by an air-cooled single-cylinder engine of block construction, producing 9 hp, or 6.6 kW, at 3,600 rpm, running through a gearbox with three forward gears and one reverse. At a weight of only 75 kg, a length of 1,900 mm, a height of 540 mm and a width of 532 mm, with front tyres sized 4.00-10 in an agricultural cleat pattern, the machine is a very light single-axle tractor with a top speed of 11.9 km/h.
Block construction combines the engine, gearbox and axle in one compact unit without a frame, making such small tractors light and manoeuvrable and well suited to working between narrow rows of trees or on small, irregularly shaped plots, as found in horticulture and viticulture. The choice between petrol and diesel engines let operations pick a machine to suit fuel availability and the type of work.
When buying such an old and light single-axle tractor secondhand, the condition of the combined engine-gearbox-axle block matters most, since in the event of a fault these parts are replaced not individually but as a unit. Also worth checking are the tyres, clutch and brakes, and, on the diesel version, the injection pump; spare parts for Holder small tractors of this size are still available from specialist dealers.
Sources: SpecCodex-Register: Kennwerte des Modells Holder E300B/E300D
Technical data
Engine
| Fuel | Benzin/Dieselcorrect |
|---|---|
| Power | 9 hp (6.6 kW)correct |
| Rated speed | 3,600 rpmcorrect |
| Cylinders | 1correct |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 1,900 mmcorrect |
|---|---|
| Width | 532 mmcorrect |
| Height | 540 mmcorrect |
| Unladen weight | 75 kgcorrect |
Drivetrain and chassis
| Gearbox | 3V/1Rcorrect |
|---|---|
| Front tyres | 4, 00 x 10 AScorrect |
| Top speed | 11.9 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 88 kW/t (7 kW / 0.1 t)
Power class: Compact (< 40 hp)
Stronger than 1% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Gbr Holder GmbH & Co E300B / E300D have?
The Gbr Holder GmbH & Co E300B / E300D delivers 9 hp.
How much does the Gbr Holder GmbH & Co E300B / E300D weigh?
The unladen weight is 75 kg.
What engine does the Gbr Holder GmbH & Co E300B / E300D have?
1 cylinders, Benzin/Diesel.
How fast does the Gbr Holder GmbH & Co E300B / E300D go?
Top speed is 11.9 km/h.
What are the dimensions of the Gbr Holder GmbH & Co E300B / E300D?
1,900 mm × 532 mm × 540 mm.
When was the Gbr Holder GmbH & Co E300B / E300D built?
Production years: 1980–19XX.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
