FPT Industrial 854F-E34T 3916/2500
Built: 2013-2016 · Series: 854F-E34T
More machines from model year 2013
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
FPT Industrial 854F-E34T – nonroad diesel engine from Turin: EPA-certified, 3.4-litre displacement, four-cylinder, 45 to 55 kW, Tier 4 Final, model years 2013 to 2016
FPT Industrial is the engine division of the Iveco/CNH group, headquartered in Turin. The 854F-E34T is a four-cylinder inline engine with turbocharger and direct injection; the EPA engine-family codes such as DFPXL03.4BPC or EFPXL03.4BPC point, via the code 03.4, to a displacement of around 3.4 litres.
Read on 3 more paragraphs
The register lists here 6 versions with 45 to 55 kW rated output at 1,800 to 2,500 rpm, with bore and stroke each of 99 to 110 mm. Maximum torque ranges from 243 to 321 Nm at 1,400 to 1,600 rpm. The specified fuel is ultra-low-sulphur diesel at 7 to 15 ppm, injection is direct, and forced induction is by waste-gate turbocharger. All versions are certified to Tier 4 (Final or Phase-in), fall into the 37 to below 56 kW power category, and date from model years 2013 to 2016.
The 854F-E34T belongs to FPT Industrial's compact F5 engine family, fitted in tractors, construction machinery, forklifts and generator sets of many outside brands; in the power range below 56 kW, FPT competes here chiefly with Kubota, Deutz and Yanmar. The four engine-family variants DFPXL03.4BPC, EFPXL03.4BPC, FFPXL03.4BPC and GFPXL03.4BPC show the base engine was certified in several closely related tunes for different applications.
On a used purchase, operating hours and the service history of the injection system count, along with the condition of the waste-gate turbocharger, the tightness of the charge-air ducting, and on Tier 4 Final versions the function of the exhaust aftertreatment. The condition of the radiator and hoses is also worth checking, since in nonroad use the engine often runs in dusty conditions under sustained load. Cooling system and parts supply run through the CNH/FPT network.
Sources: SpecCodex register, model data: FPT Industrial 854F-E34T, FPT Industrial (manufacturer)
Technical data
Engine
| Engine code | F5HFL464J*Fcorrect |
|---|---|
| Engine family | EFPXL03.4BPCcorrect |
| Engine families | DFPXL03.4BPCcorrect |
| Fuel | 7-15 ppm Ultra Low Sulfur Dieselcorrect |
| Rated output | 55 kWcorrect |
| Power band | 37<=kW<56correct |
| Rated speed | 2,500 rpmcorrect |
| Maximum torque | 291 N·mcorrect |
| Speed at max. torque | 1,600 rpmcorrect |
| Cylinders | 4correct |
| Cylinder layout | in linecorrect |
| Bore | 99 mmcorrect |
| Stroke | 110 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
| Turbocharger type | wastegate turbochargercorrect |
| Charge-air cooling | aircorrect |
| Emissions stage | Tier 4 (Final or Phase In)correct |
Origin and approval
| Version | F5HFL464J*Fcorrect |
|---|---|
| Built from | 2013correct |
| Built to | 2013correct |
| Model year from | 2013correct |
| Model year to | 2016correct |
| Sales region | bothcorrect |
Frequently asked questions
How much power does the FPT Industrial 854F-E34T 3916/2500 have?
The FPT Industrial 854F-E34T 3916/2500 delivers 55 kW.
When was the FPT Industrial 854F-E34T 3916/2500 built?
Production years: 2013-2016.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
