Ford RANGER SUPERCAB
Built: 1991-1997 · Series: RANGER
More machines from model year 1991
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Ford Ranger – pickup from the compact model to the Ranger trim of the F-Series: four- to eight-cylinder engines from 80 to 154.5 kW, 2.0 to 6.6-litre displacement, up to 3,500 kg gross weight
Ford used the Ranger name for two different lineages: the compact pickup that replaced the Courier in North America in 1983 and, from 1998, the global model built initially in Thailand and sold across Europe, southern Africa and Asia, and, in the 1960s to 1980s, the Ranger trim package on the larger F-100/F-150/F-250, which explains the heavier eight-cylinder versions carried in the register. The current generation, built since 2011 in Thailand and South Africa, carries the XL, XLT, Wildtrak and Raptor designations for equipment and off-road specification.
Read on 3 more paragraphs
The register lists 63 versions with 80 to 154.5 kW from four- to eight-cylinder engines of 1,991 to 6,600 cm³, unladen weights of 1,245 to 2,834 kg, gross vehicle weights of 1,723 to 3,500 kg, lengths of 4,765 to 5,670 mm and widths of 1,640 to 2,050 mm.
As a double-cab pickup with around a tonne of payload, the Ranger covers the mid-size pickup segment and competes in Europe with the Volkswagen Amarok (a badge-engineered sister model since 2022), the Toyota Hilux and the Mitsubishi L200, and in North America additionally with the smaller Chevrolet Colorado; use ranges from trade vehicles to leisure and fleet duty.
When buying used, check frame corrosion behind the rear axle and at the leaf-spring mounts, on the turbodiesels (2.2/3.2 TDCi, 2.0 EcoBlue) the intercooler, DPF and injectors, on four-wheel-drive versions the transfer case and, on older manual-hub models, the locking hubs, plus wear on the load bed and tow hitch; parts run through Ford's global network, with older US models sometimes relying on importers.
Sources: SpecCodex register, model data: Ford Ranger, Ford Motor Company
Technical data
Engine
| Cylinders | 6correct |
|---|---|
| Displacement | 3,950 cm³correct |
Dimensions and weights
| Width | 1,730 mmcorrect |
|---|---|
| Wheelbase | 3,210 mmcorrect |
| Unladen weight | 1,625 kgcorrect |
| Gross vehicle weight | 2,213 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|
Frequently asked questions
How much does the Ford RANGER SUPERCAB weigh?
The unladen weight is 1,625 kg.
What is the gross vehicle weight of the Ford RANGER SUPERCAB?
2,213 kg.
What engine does the Ford RANGER SUPERCAB have?
6 cylinders, 3,950 cm³ displacement.
When was the Ford RANGER SUPERCAB built?
Production years: 1991-1997.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 9 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
