Ford F 250 Crew Cab

Built: 2002-2006 · Series: Trucks 3.5–12 t (Class N2)

More machines from model year 2002

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the F 250 Crew Cab, Ford offers a model from the Trucks 3.5–12 t (Class N2) series. Production: 2002-2006. The engine delivers 240 kW, has 8 cylinders, with a displacement of 5,949 cm³. The vehicle is 5,990 mm long and 2,040 mm wide. The unladen weight is 3,400 kg. The wheelbase measures 3,980 mm. The gross vehicle weight is 4,536 kg. The vehicle runs on 4 wheels. The Trucks 3.5–12 t (Class N2) series covers 324 models. Rated output within it ranges from 48 to 475 kW; the F 250 Crew Cab sits in the middle of that range with 240 kW. Its immediate neighbours are the F-250 SUPERCAB below it with 239 kW and the 250 XL above it with 242 kW. Unladen weight within it ranges from 2,036 to 8,975 kg; here the F 250 Crew Cab sits in the lower part of that range with 3,400 kg. 5516 Ford models across 101 series are on record.

Ford Super Duty — where the heavy range begins: from the entry-level F-250 to the F-750, with the 6.7-litre Power Stroke diesel as the range's defining engine

Super Duty is not a trim line but a range of its own: Ford introduced it in 1998 for the 1999 model year, covering commercial trucks above 8,500 lb gross vehicle weight — around 3,900 kilograms. Everything below stays with the F-150 and its relatives.

Read on 4 more paragraphs

The number gives the class, not the size of the engine. The F-250 marks the entry to the range and is also its volume leader: for buyers needing more than a half-ton but not the dual rear wheels or higher ratings of an F-350 or F-450. Upwards the range runs to the F-750.

Manufacturing separates the classes too. The F-250 through F-550 are assembled at the Kentucky Truck Plant in Louisville; the heavy F-650 and F-750 at the Blue Diamond plant in Mexico. Comparing two vehicles, do not assume an F-750 is simply a larger F-250 — these are different vehicle concepts under one name.

The engine that defines the range is the 6.7-litre Power Stroke diesel. In standard form it produces 475 hp and 1,050 lb-ft of torque; the High-Output version 500 hp and 1,200 lb-ft. For payload context: an F-150 tops out near 2,440 lb, an F-250 carries more than 4,200 lb.

Under European registration logic, vehicles of this gross weight (3,502 to 11,990 kg) fall into class N2 (3.5 to 12 t); their commercial use requires, depending on weight, a category C1 or C driving licence, plus a tachograph, driving and rest times and, in many European countries, a distance-based toll. As straight pick-ups and cab-chassis without a fifth-wheel coupling, they remain rigid vehicles, not tractor units.

Sources: SpecCodex register, model data: Ford Lkw Klasse N2

Technical data

Engine

Power240 kWcorrect
Cylinders8correct
Displacement5,949 cm³correct

Dimensions and weights

Length5,990 mmcorrect
Width2,040 mmcorrect
Wheelbase3,980 mmcorrect
Unladen weight3,400 kgcorrect
Gross vehicle weight4,536 kgcorrect

Drivetrain and chassis

Wheels4correct

Where this model stands

Power-to-weight ratio: 70.6 kW/t (240 kW / 3.4 t)

Stronger than 39% of the trucks in the register — out of 25,242 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Ford F 250 Crew Cab have?

The Ford F 250 Crew Cab delivers 240 kW.

How much does the Ford F 250 Crew Cab weigh?

The unladen weight is 3,400 kg.

What is the gross vehicle weight of the Ford F 250 Crew Cab?

4,536 kg.

What engine does the Ford F 250 Crew Cab have?

8 cylinders, 5,949 cm³ displacement.

What are the dimensions of the Ford F 250 Crew Cab?

5,990 mm × 2,040 mm.

When was the Ford F 250 Crew Cab built?

Production years: 2002-2006.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 12 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
