Ford 681
Built: 1958–1962 · Series: 601 er-Baureihe
More machines from model year 1958
Ford 681: water-cooled four-cylinder tractor from the 601 series with petrol, LPG or diesel engine, 2,190 cc, 35.6 kW and 1,492 kg weight, built 1958 to 1962
Ford was an American vehicle manufacturer whose tractor division built its own farm machinery before it was sold to the Italian Fiat group in 1991 and absorbed into New Holland. The 601 series was offered from 1958 as the successor to the previous Ford tractor generation, with the same basic tractor available, depending on version, with a petrol, LPG or diesel engine.
Read on 3 more paragraphs
The 681 is powered by a water-cooled four-cylinder engine of 2,190 cc, producing 48.4 hp, or 35.6 kW, and 164 Nm of torque at 2,000 to 2,200 rpm. At a weight of 1,492 kg, a length of 3,069 mm, a height of 1,446 mm and a width of 1,623 mm, with a wheelbase of 1,892 mm, it is a medium-sized field tractor with a top speed of 28 km/h.
Offering the same tractor with three different fuel types allowed farms to match the drivetrain to whichever fuel supply was cheapest or most readily available; LPG engines were considered comparatively smooth-running and low in maintenance next to petrol engines of the same period. A four-cylinder tractor of this kind was used for tillage, trailer work and driving mounted implements through the power take-off.
When buying a Ford 681 secondhand, the first thing that matters is which of the three fuel types the particular machine runs on, since the carburettor, vaporiser or injection pump differ fundamentally and call for correspondingly different spare parts. Also worth checking are wear in the clutch and gearbox, the condition of the cooling system, and corrosion on sheet-metal and frame parts.
Sources: SpecCodex-Register: Kennwerte des Modells Ford 681
Technical data
Engine
| Fuel | Benzin/LPG/Dieselcorrect |
|---|---|
| Power | 48.4 hp (35.6 kW)correct |
| Rated speed | 2.000/2.200 rpmcorrect |
| Torque | 164 Nmcorrect |
| Speed at max. torque | 1,600 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 2,190 cm³correct |
| Bore | 87.31 mmcorrect |
| Stroke | 91.44 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,069 mmcorrect |
|---|---|
| Width | 1,623 mmcorrect |
| Height | 1,446 mmcorrect |
| Wheelbase | 1,892 mmcorrect |
| Ground clearance | 533 mmcorrect |
| Unladen weight | 1,492 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 4 V/1 R, 10 V/2 R and 12 V/3 Rcorrect |
| Front tyres | 5.50-16 ASFcorrect |
| Rear tyres | 11-28 AScorrect |
| Top speed | 28 km/hcorrect |
Where this model stands
Power-to-weight ratio: 23.9 kW/t (36 kW / 1.5 t)
Power class: Universal (40–100 hp)
Stronger than 33% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Ford 681 have?
The Ford 681 delivers 48.4 hp.
How much does the Ford 681 weigh?
The unladen weight is 1,492 kg.
What engine does the Ford 681 have?
4 cylinders, 2,190 cm³ displacement, Benzin/LPG/Diesel.
How fast does the Ford 681 go?
Top speed is 28 km/h.
What are the dimensions of the Ford 681?
3,069 mm × 1,623 mm × 1,446 mm.
When was the Ford 681 built?
Production years: 1958–1962.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
