Fendt 612LS
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Fendt 612LS is a tractor from the Fendt family, assigned to the 600 series. Developed within the Vario line, it features a cabin and a turbo‑clutch drive. It is powered by a 6‑cylinder engine with a displacement of 6 234 cm³ delivering a nominal output of 135 hp (98.8 kW) at 2 400 rpm. The maximum torque of 490 Nm provides strong pulling capability, while the shaft speed of 750/1000 rpm is suitable for attaching field implements. With a curb weight of 7 025 kg, a length of 4 800 mm, width of 2 204 mm, height of 2 860 mm and a wheelbase of 2 715 mm, the machine offers stable handling. The 20‑speed Vario transmission with nine reverse gears and a fuel tank capacity of 222 l ensure long operating periods. The Cat III lift category allows handling of heavy loads.
In operation, the 135‑hp power means the 612LS can deliver sufficient drawbar pull for medium to heavy field tasks such as plowing or mowing large areas. The high torque enables smooth starts under load, and the extensive gear range permits fine speed adjustments without frequent shifting. The relatively high curb weight reduces ground pressure, which is advantageous on soft soils. The large 222‑l tank reduces refuelling stops during long workdays.
The 612LS is typically employed for jobs that require a tractor from the 600 series with moderate power. It is suited for agricultural enterprises performing field work, transport and light implement operations, benefiting from the combination of adequate power, robust construction and a comprehensive transmission.
Fendt – other models: the collective page of tractors outside the named ranges, from the Farmer and Favorit types of the LS and LSA era (308 LSA, 312 LSA) through the narrow-track 200 V/F/P to the Vario generations 300
This page gathers the Fendt tractors the register could not assign to a named range – the brand from Marktoberdorf in the Allgäu that began in 1930 with the Dieselross, presented with the Vario in 1995 the first production-ready stepless transmission in farm machinery and has belonged to AGCO since 1997. The type logic: the Farmer and Favorit ranges of the 1970s to 1990s give the range and size in the three-digit number (Farmer 308 as a 300, Favorit 612 as a 600), LS, LSA and Turbomatik the equipment, cab and turbo-clutch drive; since 1995 all tractors are called Vario, with the first digit as range (200 to 1000) and the following ones as power step – 312 Vario about 120 hp, 724 Vario about 240 hp, 1050 Vario about 500 hp – the suffixes V, F and P mark the narrow-track models of the 200s for vineyard, orchard and plantation, Gen3 to Gen7 the generations, Profi and Power the equipment lines. The engines came from MWM and Deutz in the old, Sisu and AGCO Power in the medium and MAN in the big 900 and 1000 ranges.
Read on 3 more paragraphs
The register lists here 204 versions with 3 to 368 kW from one- to six-cylinders of 308 to 12,419 cm³, PTO outputs from 106 to 300 hp on the recorded big tractors, torque from 204 to 2,400 Nm, unladen weights from 510 to 23,000 kg, lengths from 2,750 to 6,157 mm and widths from 1,073 to 3,000 mm.
Fendt is the premium brand of European farm machinery with the highest resale value and Germany's market leader for years; the 1050 Vario is the most powerful standard wheeled tractor, the 200 V the best-selling vineyard tractor.
On used tractors, operating hours, Vario transmission (oil history, calibration), engine and exhaust aftertreatment, front-axle and cab suspension, electronics and terminal, on the LS and LSA types turbo clutch and gearbox count; parts run through the AGCO network.
Sources: SpecCodex register, model data: Fendt (weitere Modelle), Fendt (AGCO, Hersteller, Marktoberdorf)
Technical data
Engine
| Power | 135 hp (98.8 kW)correct |
|---|---|
| Rated speed | 2,400 rpmcorrect |
| Torque | 490 Nmcorrect |
| Cylinders | 6correct |
| Displacement | 6,234 cm³correct |
Dimensions and weights
| Length | 4,800 mmcorrect |
|---|---|
| Width | 2,204 mmcorrect |
| Height | 2,860 mmcorrect |
| Wheelbase | 2,715 mmcorrect |
| Unladen weight | 7,025 kgcorrect |
Drivetrain and chassis
| Gearbox | 20V/9Rcorrect |
|---|---|
| Forward gears | 20correct |
| Reverse gears | 9correct |
Working data
| Fuel tank capacity | 222 lcorrect |
|---|
Other data
| Linkage category | Cat IIIcorrect |
|---|---|
| PTO speed | 750/1000 rpmcorrect |
Where this model stands
Power-to-weight ratio: 14.1 kW/t (99 kW / 7 t)
Power class: Large (100–180 hp)
Stronger than 79% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Fendt 612LS have?
The Fendt 612LS delivers 135 hp.
How much does the Fendt 612LS weigh?
The unladen weight is 7,025 kg.
What engine does the Fendt 612LS have?
6 cylinders, 6,234 cm³ displacement.
What are the dimensions of the Fendt 612LS?
4,800 mm × 2,204 mm × 2,860 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
