Fendt 209 PA
Built: 2002–2009 · Series: 200er-Reihe
More machines from model year 2002
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Fendt 200 Series – Compact Class Across Three Decades, 1981 to 2009: three- and four-cylinder diesels with 29.3 to 66 kW (40 to 90 hp), 2,826 to 4,314 cm³ displacement
The 200 series covers Fendt's compact power class and is documented in the register from 1981 to 2009, from the early Farmer 204 V to modern models such as the 209 VA. Output of the recorded models ranges from 29.3 to 66 kW, with models rated in horsepower spanning 40 to 90 hp, using three- and four-cylinder engines with displacement from 2,826 to 4,314 cm³.
Read on 3 more paragraphs
Recorded operating weight runs from 2,030 to 3,130 kg, wheelbase from 2,027 to 2,221 mm, and top speed of the listed models spans 30 to 40 km/h. Suffixes such as V, F or P in model names denote different body and mounting variants, such as narrow-track models for vineyards.
The 200 series consistently targeted smaller farms, specialty crops and grassland operations. For a used model, the exact production year matters most, as cab, hydraulics and engine technology differ considerably between the early 1980s and late 2000s model years.
Across the long production run from 1981 to 2009, later 200-series models already fell under the European emissions stages, which from 1999 introduced step-by-step limits on soot and nitrogen oxides for new tractors, while early model years still ran without any emissions certification. For PTO and lift, this power class consistently used the 540 rpm standard with a category I three-point hitch, needed by narrow-track vineyard versions just as much as by the wider standard models.
Sources: SpecCodex register, model data: Fendt 200er-Reihe, Fendt
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 90 hp (66 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Torque | 339 Nmcorrect |
| Speed at max. torque | 1,500 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,314 cm³correct |
| Bore | 102 mmcorrect |
| Stroke | 132 mmcorrect |
| Injection pressure | 1,000 barcorrect |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 3,665 mmcorrect |
|---|---|
| Width | 1,666 mmcorrect |
| Height | 2,420 mmcorrect |
| Wheelbase | 2,221 mmcorrect |
| Ground clearance | 295 mmcorrect |
| Unladen weight | 2,905 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 21V/6Rcorrect |
| Front tyres | 280/80 R 18correct |
| Rear tyres | 380/85 R 28correct |
| Top speed | 40 km/hcorrect |
Working data
| Fuel tank capacity | 70 lcorrect |
|---|
Origin and approval
| Units built | 399correct |
|---|
Other data
| Linkage category | Cat IIcorrect |
|---|---|
| PTO speed | 540/750/1000 rpmcorrect |
Where this model stands
Power-to-weight ratio: 22.7 kW/t (66 kW / 2.9 t)
Power class: Universal (40–100 hp)
Stronger than 60% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Fendt 209 PA have?
The Fendt 209 PA delivers 90 hp.
How much does the Fendt 209 PA weigh?
The unladen weight is 2,905 kg.
What engine does the Fendt 209 PA have?
4 cylinders, 4,314 cm³ displacement, Diesel.
How fast does the Fendt 209 PA go?
Top speed is 40 km/h.
What are the dimensions of the Fendt 209 PA?
3,665 mm × 1,666 mm × 2,420 mm.
When was the Fendt 209 PA built?
Production years: 2002–2009.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
