Fendt 207 V/F

Built: 2009 · Series: 200 V/F

More machines from model year 2009

Source: https://www.technikboerse.at/gebraucht/traktor-1/fendt-370/2

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 200 V/F series from Fendt includes the 207 V/F. Production: 2009. The engine delivers 70 hp (51 kW), has 3 cylinders, with a displacement of 3,236 cm³. Torque is 295 Nm. Rated speed is 2,100 rpm. The machine is 3,578 mm long, 1,070 mm wide and 2,360 mm high. The unladen weight is 22,760 kg. The wheelbase measures 2,160 mm. Top speed is 30 km/h. The tank holds 76 litres. Transmission: continuously variable. The engine is water-cooled. Tyres: front 10.0/75-15.3, rear 12.4 R 24. The fuel is Diesel/RME. The bore measures 108 mm. The stroke is 120 mm. Maximum torque is reached at 1,600 rpm. Construction: unit construction (no separate frame). The PTO runs at 540/540E/1000 rpm. Rated output across the Fendt range ranges from 4 to 553 hp; the 207 V/F sits at the bottom of that range with 70 hp. Its immediate neighbours are the 206 VA below it with 65.3 hp and the 207 Vario above it with 72 hp. Rated output across the Fendt range ranges from 9 to 540 hp; here the 207 V/F sits at the bottom of that range with 70 hp. 1545 Fendt models across 89 series are on record.

Fendt 207 V/F (2009): narrow-track vineyard and orchard tractor from the 200 V/F range with a 3,236cc three-cylinder diesel, 51 kW and just 1,070 mm of width

Fendt builds its tractors in Marktoberdorf, Bavaria, and has been part of the AGCO group since 1997. The V/F designation marks narrow-track special versions at Fendt for vineyards (V) and orchards (F), which must pass between narrow rows where a standard tractor would not fit.

Read on 3 more paragraphs

The Fendt 207 V/F carries a water-cooled three-cylinder diesel engine with 3,236 cm³ of displacement, producing 70 hp, or 51 kW, at 2,100 rpm, with 295 Nm of torque; it runs on diesel or RME. At just 1,070 mm wide, 2,360 mm high, 3,578 mm long and with a 2,160 mm wheelbase, the narrow machine reaches a top speed of 30 km/h.

At just over a metre wide, the 207 V/F passes through rows too narrow for an ordinary farm tractor, while its three cylinders and 51 kW remain strong enough for mulchers, sprayers and haul trailers in the vineyard or orchard. The 30 km/h design top speed falls under German driving licence class L.

When buying a narrow-track vineyard or orchard tractor used, the condition of the mudguards and door mirrors matters, as these are often grazed when working in tight rows, along with the tightness of the hydraulic connections for sprayers and mulchers. Also worth checking are the steering, which carries a heavier load on a narrow-track chassis, and corrosion damage to the frame and axles from frequent contact with crop-protection products.

Sources: SpecCodex-Register: Kennwerte des Modells Fendt 207 V/F, Fendt (manufacturer)

Technical data

Engine

Fuel	Diesel/RMEcorrect
Power	70 hp (51 kW)correct
Rated speed	2,100 rpmcorrect
Torque	295 Nmcorrect
Speed at max. torque	1,600 rpmcorrect
Cylinders	3correct
Displacement	3,236 cm³correct
Bore	108 mmcorrect
Stroke	120 mmcorrect
Cooling	water-cooledcorrect

Dimensions and weights

Length	3,578 mmcorrect
Width	1,070 mmcorrect
Height	2,360 mmcorrect
Wheelbase	2,160 mmcorrect
Unladen weight	22,760 kgcorrect

Drivetrain and chassis

Drive	four-wheel drivecorrect
Gearbox	continuously variablecorrect
Front tyres	10.0/75-15.3correct
Rear tyres	12.4 R 24correct
Top speed	30 km/hcorrect

Working data

Fuel tank capacity	76 lcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Other data

PTO speed	540/540E/1000 rpmcorrect

Where this model stands

Power-to-weight ratio: 2.2 kW/t (51 kW / 22.8 t)

Power class: Universal (40–100 hp)

Stronger than 47% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Fendt 207 V/F have?

The Fendt 207 V/F delivers 70 hp.

How much does the Fendt 207 V/F weigh?

The unladen weight is 22,760 kg.

What engine does the Fendt 207 V/F have?

3 cylinders, 3,236 cm³ displacement, Diesel/RME.

How fast does the Fendt 207 V/F go?

Top speed is 30 km/h.

What are the dimensions of the Fendt 207 V/F?

3,578 mm × 1,070 mm × 2,360 mm.

When was the Fendt 207 V/F built?

Production years: 2009.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
