Eicher 365 S
Built: 1976–1979 · Series: Schmalspur 3700
More machines from model year 1976
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Eicher 365 S (narrow-track 3700): air-cooled four-cylinder narrow-track tractor from Bavaria with 65 hp, a weight of 1,780 kg and a width of 1,400 mm, built from 1976 to 1979
The 365 S belongs to the narrow-track 3700 range of the Bavarian manufacturer Eicher and was built between 1976 and 1979. Like the smaller narrow-track models, the range was designed for work between closely planted tree or vine rows, but with four cylinders instead of two and considerably more power it turned out noticeably larger than the slimmer earlier models in this product family.
Read on 3 more paragraphs
The air-cooled four-cylinder diesel engine of 3,927cc produces 65 hp (48 kW) at 2,150 rpm. At 1,780 kg, 3,400 mm long, 1,200 mm high and 1,400 mm wide, the 365 S is markedly stronger and longer than a simple two-cylinder narrow-track tractor; the wheelbase is 2,150 mm and the top speed 25 km/h.
With four cylinders and 65 hp, the 365 S covers the upper power class within the narrow-track family, making it suited to row crops with a wider row spacing, such as larger orchards or hop gardens, where the smaller two-cylinder models reach the limit of their pulling power. The air-cooled four-cylinder engine offers the same frost resistance as the range's smaller engines.
When buying one of these tractors second-hand, the condition of the air-cooled cylinder heads and the cooling-fan belts matters, since a failure of the cooling-air ducting on the four-cylinder engine leads to overheating faster than on the smaller engines. Also worth checking are the clutch and gearbox for wear from working with heavy mounted implements, and the narrow axle construction for play and corrosion caused by plant-protection chemicals.
Sources: SpecCodex-Register: Kennwerte des Modells 365 S
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 65 hp (48 kW)correct |
| Rated speed | 2,150 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,927 cm³correct |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 3,400 mmcorrect |
|---|---|
| Width | 1,400 mmcorrect |
| Height | 1,200 mmcorrect |
| Wheelbase | 2,150 mmcorrect |
| Ground clearance | 320 mmcorrect |
| Unladen weight | 1,780 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | Hurth 932correct |
| Front tyres | 7, 5-15correct |
| Rear tyres | 11, 2-28correct |
| Top speed | 25 km/hcorrect |
Working data
| Fuel tank capacity | 57 lcorrect |
|---|
Origin and approval
| Construction | Blockcorrect |
|---|---|
| Units built | 289correct |
Where this model stands
Power-to-weight ratio: 27 kW/t (48 kW / 1.8 t)
Power class: Universal (40–100 hp)
Stronger than 45% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Eicher 365 S have?
The Eicher 365 S delivers 65 hp.
How much does the Eicher 365 S weigh?
The unladen weight is 1,780 kg.
What engine does the Eicher 365 S have?
4 cylinders, 3,927 cm³ displacement, Diesel.
How fast does the Eicher 365 S go?
Top speed is 25 km/h.
What are the dimensions of the Eicher 365 S?
3,400 mm × 1,400 mm × 1,200 mm.
When was the Eicher 365 S built?
Production years: 1976–1979.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
