Doosan MEGA200TC

Series: Doosan Integrated Tool Carrier

Source: http://www.xcmg.com/solution/opencast-mining.htm

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Doosan MEGA200TC belongs to the Doosan Integrated Tool Carrier series. The engine delivers 145 hp (102.9 kW), has 6 cylinders, with a displacement of 5,784.6 cm³. Torque is 558.6 Nm. Rated speed is 2,200 rpm. The unladen weight is 11,000 kg. The wheelbase measures 2,901.7 mm. Ground clearance is 371.9 mm. The tank holds 260.1 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,500 rpm. The hydraulic tank holds 150.3 litres. The cooling system holds 31 litres. The oil fill is 21.2 litres. The electrical system runs on 24 V. The engine fitted is the DB58Ti. Tyre size: 17,5x25-12PR (L2). The Doosan Integrated Tool Carrier series covers 4 models. Rated output within it ranges from 111.5 to 164.2 hp; the MEGA200TC sits in the upper part of that range with 145 hp. Its immediate neighbours are the MEGA160TC below it with 111.5 hp and the DL250TC above it with 164.2 hp. 314 Doosan models across 20 series are on record. The model is listed under Telehandlers. 22 verified figures from 1 source are on file.

Technical data

Engine

Engine model	DB58Ticorrect
Power	145 hp (102.9 kW)correct
Rated speed	2,200 rpmcorrect
Torque	558.6correct
Speed at max. torque	1,500 rpmcorrect
Cylinders	6correct
Displacement	5,784.6 cm³correct
Aspiration	turbo after cooledcorrect
Coolant capacity	31 lcorrect
Engine oil capacity	21.2 lcorrect

Dimensions and weights

Wheelbase	2,901.7correct
Ground clearance	371.9correct
Unladen weight	11,000 kgcorrect

Drivetrain and chassis

Gearbox type	auto power-shift countershaftcorrect
Forward gears	4correct
Reverse gears	3correct
Tyre size	17.5x25-12PR (L2)correct
System voltage	24 Vcorrect

Working data

Hydraulic oil capacity	150.3 lcorrect
Fuel tank capacity	260.1 lcorrect

Other data

Height	3,182.1correct

Where this model stands

Power-to-weight ratio: 9.4 kW/t (103 kW / 11 t)

Stronger than 83% of the telehandlers in the register — out of 658 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Doosan MEGA200TC have?

The Doosan MEGA200TC delivers 145 hp.

How much does the Doosan MEGA200TC weigh?

The unladen weight is 11,000 kg.

What engine does the Doosan MEGA200TC have?

6 cylinders, 5,785 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
