Deutz-Fahr AgroCompact 3.90 F/S
Built: 1992–1996 · Series: AgroCompact
More machines from model year 1992
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Deutz-Fahr AgroCompact 3.90 F/S: narrow-bodied air-cooled four-cylinder tractor with 4,085 cm³ displacement, 75 hp (55.2 kW) and just 1,200 mm width
Deutz-Fahr built the AgroCompact range as compact, narrow-bodied tractors for tasks where standard tractors are too wide. The AgroCompact 3.90 F/S belongs to this narrow body style.
Read on 3 more paragraphs
The four-cylinder diesel engine with 4,085 cm³ displacement is air-cooled and produces 75 hp, or 55.2 kW, at 2,350 rpm, with torque of 250 Nm. At just 1,200 mm width, with 2,250 kg weight, 3,470 mm length and 2,100 mm height, the AgroCompact is markedly narrower than comparably heavy standard tractors.
With a top speed of 30 km/h, the AgroCompact 3.90 F/S falls into driving licence category L (up to 40 km/h). The narrow track width of 1,200 mm suits the machine to work in tight lanes, such as between row crops or in plantings with narrow row spacing, where a standard tractor would not fit.
When buying an AgroCompact, check the condition of the narrow axles and steering joints, which see greater strain working in tight lanes. Also check the cooling-air ducting of the air-cooled four-cylinder engine, the clutch and gearbox, and the availability of spare parts for this narrow special body style. The front hydraulics and the couplings for narrow implements should also be checked, since implements built specifically for this narrow range have become scarce, and finding replacements often takes considerable effort.
Sources: SpecCodex-Register: Kennwerte des Modells Deutz-Fahr AgroCompact 3.90 F/S, Deutz-Fahr (manufacturer)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 75 hp (55.2 kW)correct |
| Rated speed | 2,350 rpmcorrect |
| Torque | 250 Nmcorrect |
| Cylinders | 4correct |
| Displacement | 4,085 cm³correct |
| Bore | 102 mmcorrect |
| Stroke | 125 mmcorrect |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 3,470 mmcorrect |
|---|---|
| Width | 1,200 mmcorrect |
| Height | 2,100 mmcorrect |
| Wheelbase | 2,045 mmcorrect |
| Ground clearance | 330 mmcorrect |
| Unladen weight | 2,250 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 16V/8Rcorrect |
| Front tyres | 7, 5 L-15 ASF (A: 10.5-18 MPT)correct |
| Rear tyres | 13.6 R 24 AS (A: 14.9 R 28 AS)correct |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 24.5 kW/t (55 kW / 2.2 t)
Power class: Universal (40–100 hp)
Stronger than 52% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Deutz-Fahr AgroCompact 3.90 F/S have?
The Deutz-Fahr AgroCompact 3.90 F/S delivers 75 hp.
How much does the Deutz-Fahr AgroCompact 3.90 F/S weigh?
The unladen weight is 2,250 kg.
What engine does the Deutz-Fahr AgroCompact 3.90 F/S have?
4 cylinders, 4,085 cm³ displacement, Diesel.
How fast does the Deutz-Fahr AgroCompact 3.90 F/S go?
Top speed is 30 km/h.
What are the dimensions of the Deutz-Fahr AgroCompact 3.90 F/S?
3,470 mm × 1,200 mm × 2,100 mm.
When was the Deutz-Fahr AgroCompact 3.90 F/S built?
Production years: 1992–1996.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
