Deutz F2M 317
Built: 1935–1942 · Series: F2-Reihe
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Deutz F2M 317 (1935-1942) from Cologne: water-cooled two-cylinder diesel of 3,854 cc, 30 hp/22 kW at 1,300 rpm, weight 2,600 kg, top speed 22.5 km/h
Deutz is a company from Cologne and one of the best-known makers of tractor engines, above all its air-cooled diesels. The F2M 317 was built from 1935 to 1942 and shows that Deutz also offered larger, water-cooled models at the time: in the type designation, the 2 before the M indicates the number of cylinders and the M indicates water cooling, as confirmed by the cooling type given for this model.
Read on 3 more paragraphs
The water-cooled two-cylinder diesel engine has a displacement of 3,854 cc and produces 22 kW (30 hp) at 1,300 rpm. The F2M 317 is 3,400 mm long, 2,000 mm wide and 2,230 mm high, with a wheelbase of 1,920 mm and a weight of 2,600 kg. Its top speed is 22.5 km/h.
A two-cylinder engine of almost 3.9 litres at only 1,300 rpm is a slow-turning, large-displacement design, as built before the war for high pulling power at low revs. At 2.6 tonnes and 22 kW, the F2M 317 sat in the medium-to-larger power class of agricultural tractors of its time, built for heavier ploughing and draft work.
When buying such an old water-cooled Deutz diesel, check the radiator, water pump and tightness of the cooling system, the injection pump and nozzles, the clutch and gearbox, and rust on the frame, wings and sheet metal after some ninety years. Parts for a vehicle of this age can practically only be sourced from collectors of historic Deutz tractors and specialist restoration workshops.
Sources: SpecCodex-Register: Kennwerte des Modells Deutz F2M 317, Deutz
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 30 hp (22 kW)correct |
| Rated speed | 1,300 rpmcorrect |
| Cylinders | 2correct |
| Displacement | 3,854 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,400 mmcorrect |
|---|---|
| Width | 2,000 mmcorrect |
| Height | 2,230 mmcorrect |
| Wheelbase | 1,920 mmcorrect |
| Ground clearance | 300 mmcorrect |
| Unladen weight | 2,600 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 5V/1Rcorrect |
| Forward gears | 5correct |
| Reverse gears | 1correct |
| Front tyres | 6.50-20correct |
| Rear tyres | 12.00-20correct |
| Top speed | 22.5 km/hcorrect |
Working data
| Fuel tank capacity | 85 lcorrect |
|---|
Origin and approval
| Construction | frameless unit constructioncorrect |
|---|---|
| Units built | 268correct |
Where this model stands
Power-to-weight ratio: 8.5 kW/t (22 kW / 2.6 t)
Power class: Compact (< 40 hp)
Stronger than 16% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Deutz F2M 317 have?
The Deutz F2M 317 delivers 30 hp.
How much does the Deutz F2M 317 weigh?
The unladen weight is 2,600 kg.
What engine does the Deutz F2M 317 have?
2 cylinders, 3,854 cm³ displacement, Diesel.
How fast does the Deutz F2M 317 go?
Top speed is 22.5 km/h.
What are the dimensions of the Deutz F2M 317?
3,400 mm × 2,000 mm × 2,230 mm.
When was the Deutz F2M 317 built?
Production years: 1935–1942.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
