Deutz Allis DX 7.10
Built: 1984–1986 · Series: DX-Reihe
Successor: 7145 →
More machines from model year 1984
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Deutz Allis DX 7.10: air-cooled six-cylinder standard tractor with a Deutz engine, 6,128 cm³ displacement, 160 hp (117.1 kW) and 5,443 kg weight
Deutz Allis was the joint brand of Deutz and Allis-Chalmers for the North American tractor market of the 1980s. The DX 7.10 sits at the top of the DX range and carries a six-cylinder diesel engine built by Deutz in Cologne.
Read on 3 more paragraphs
The six-cylinder diesel engine with 6,128 cm³ displacement is air-cooled and produces 160 hp, or 117.1 kW, at 2,400 rpm, with torque of 563 Nm. At 5,443 kg weight, 4,770 mm length, 2,370 mm width and 2,730 mm height, the DX 7.10 ranks among the heaviest and most powerful Deutz Allis tractors.
With a top speed of 30 km/h, the DX 7.10 falls into driving licence category L (up to 40 km/h). The 160 hp and 563 Nm of torque from the air-cooled six-cylinder engine suffice for heavy tillage with wide implements and for pulling large trailers, as used on the wide arable fields of North America.
When buying a DX 7.10, check the condition of the cooling-air ducting on the large six-cylinder engine, whose fan and baffle plates must be intact. Also check the clutch, gearbox and axle drives under high drawbar load, and the spare-parts situation, which is more limited for this earlier Deutz Allis range than for current Deutz-Fahr models. The condition of the intake and exhaust manifolds is also worth checking, since a clogged intake screen reduces cooling airflow and shortens the life of the large six-cylinder engine under sustained heavy pulling.
Sources: SpecCodex-Register: Kennwerte des Modells Deutz Allis DX 7.10
Technical data
Engine
| Engine make | Deutzcorrect |
|---|---|
| Fuel | dieselcorrect |
| Power | 160 hp (117.1 kW)correct |
| Rated speed | 2,400 rpmcorrect |
| Torque | 563 Nmcorrect |
| Speed at max. torque | 1,799 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 6,128 cm³correct |
| Bore | 102 mmcorrect |
| Stroke | 125 mmcorrect |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 4,770 mmcorrect |
|---|---|
| Width | 2,370 mmcorrect |
| Height | 2,730 mmcorrect |
| Wheelbase | 2,826 mmcorrect |
| Ground clearance | 490 mmcorrect |
| Unladen weight | 5,443 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 36 V/12 Rcorrect |
| Front tyres | 11.00-16 ASF (4 WD: 18.4 R 26 AS)correct |
| Rear tyres | 20.8 R 38 AScorrect |
| Top speed | 30 km/hcorrect |
Origin and approval
| Plant | Germanycorrect |
|---|---|
| Construction | unit construction (no separate frame)correct |
Other data
| Predecessor | Deutz-Fahr DX 7.10correct |
|---|---|
| Successor | Deutz-Allis 7145correct |
Where this model stands
Power-to-weight ratio: 21.5 kW/t (117 kW / 5.4 t)
Power class: Large (100–180 hp)
Stronger than 85% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Deutz Allis DX 7.10 have?
The Deutz Allis DX 7.10 delivers 160 hp.
How much does the Deutz Allis DX 7.10 weigh?
The unladen weight is 5,443 kg.
What engine does the Deutz Allis DX 7.10 have?
6 cylinders, 6,128 cm³ displacement, Diesel.
How fast does the Deutz Allis DX 7.10 go?
Top speed is 30 km/h.
What are the dimensions of the Deutz Allis DX 7.10?
4,770 mm × 2,370 mm × 2,730 mm.
When was the Deutz Allis DX 7.10 built?
Production years: 1984–1986.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
