Cuppers SDO 11-10L – specifications
Built: 2017 · Series: SDO
The SDO series from Cuppers includes the SDO 11-10L. Production: 2017. The vehicle is 13,360 mm long and 2,540 mm wide. The unladen weight is 8,180 kg. The wheelbase measures 8,130 mm. Top speed is 100 km/h. The gross vehicle weight is 21,000 kg. The SDO series covers 8 models. Unladen weight within it ranges from 5,900 to 16,100 kg; the SDO 11-10L sits in the lower part of that range with 8,180 kg. Its immediate neighbours are the SDO 11 - 10 L below it with 6,360 kg and the SDO 11-16 L above it with 8,580 kg. Gross vehicle weight within it ranges from 21,000 to 39,000 kg; here the SDO 11-10L sits at the bottom of that range with 21,000 kg. 173 Cuppers models across 11 series are on record.
Data for the version built 2017 · Data origin: Official register · sources
More machines from model year 2017
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Cuppers SDO – low-loader semi-trailers from 21 to 39 t gross weight: L, AL and SL versions, 12.1 to 14 m long for heavy and machinery transport
Cuppers' SDO series comprises low-loader semi-trailers for heavy transport, offered in several build sizes from SDO 11 to SDO 15 with different axle and frame configurations. The letter suffixes L, AL and SL distinguish variants of the same base type, among other things in load-bed layout or axle configuration.
Read on 3 more paragraphs
The register lists 8 versions here with unladen weights from 5,900 to 16,100 kg and gross weights from 21,000 to 39,000 kg. Lengths range from 12,100 to 14,000 mm, widths from 2,500 to 2,600 mm.
With lengths of up to 14 metres and gross weights up to 39 tonnes, the SDO semi-trailers rank among the heavy low-loaders used in European road haulage for construction machinery, agricultural equipment and industrial plant, where a low loading height matters for tall or bulky goods.
When buying used, check the frame and main beams for cracks and deformation, the axle assemblies and air suspension, the kingpin and the wear plates of the bearing surface, and the brake system with its connections. On the longer versions, also assess frame torsional stiffness; axles and brake components are supplied by the independent commercial-vehicle parts trade. On the AL versions with an extra axle, check that the load is distributed evenly across all axles. A test of the working lights and the reflective marking required for oversized loads should also be part of the inspection.
Sources: SpecCodex register, model data: Cuppers SDO
Technical data
Dimensions and weights
| Length | 13,360 mmcorrect |
|---|---|
| Width | 2,540 mmcorrect |
| Coupling-to-axle distance | 8,130 mmcorrect |
| Unladen weight | 8,180 kgcorrect |
| Gross vehicle weight | 21,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
