Cnh Steyr CVT 6200
Built: 2009–2012 · Series: CVT - Vierte Generation
More machines from model year 2009
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Steyr CVT 6200 (fourth CVT generation, 2009–2012): six-cylinder diesel with 6,728 cm³, a stepless transmission and 145 kW
Steyr developed continuously variable transmissions for its tractors in the CVT range, built in St. Valentin, Austria, within the CNH group. The fourth generation of this CVT range was built from 2009 to 2012, with the CVT 6200 as its version in the upper power bracket.
Read on 3 more paragraphs
The Steyr CVT 6200 carries a water-cooled six-cylinder diesel engine with 6,728 cm³ of displacement, producing 197 hp, or 145 kW, at 2,200 rpm, and able to run on diesel or biodiesel. At 7,200 kg, 5,017 mm long, 3,090 mm high, 2,682 mm wide and with a 2,884 mm wheelbase, the machine reaches a top speed of 40 km/h.
The stepless CVT transmission keeps the six-cylinder engine within its economical speed range regardless of travel speed, whether ploughing at a crawl or hauling near top speed, without the driver having to shift gears. At 145 kW and 6,728 cm³, the CVT 6200 ranks among the more powerful standard tractors for large-scale field and draft work.
When buying a CVT tractor used, the condition of the stepless transmission itself matters most, as repairing it is more involved and costlier than a conventional gearbox; a test drive across the whole speed range is worthwhile for that reason. Also worth checking are cooling performance under full load, the tightness of the hydraulic connections, and the condition of the clutch plates in the drivetrain.
Sources: SpecCodex-Register: Kennwerte des Modells Steyr CVT 6200, Steyr (manufacturer)
Technical data
Engine
| Fuel | Diesel / Biodieselcorrect |
|---|---|
| Power | 197 hp (145 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 6,728 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 5,017 mmcorrect |
|---|---|
| Width | 2,682 mmcorrect |
| Height | 3,090 mmcorrect |
| Wheelbase | 2,884 mmcorrect |
| Unladen weight | 7,200 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | continuously variablecorrect |
| Front tyres | 600 / 65 R 28correct |
| Rear tyres | 650 / 65 R 42correct |
| Top speed | 40 km/hcorrect |
Where this model stands
Power-to-weight ratio: 20.1 kW/t (145 kW / 7.2 t)
Power class: Heavy (> 180 hp)
Stronger than 91% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Cnh Steyr CVT 6200 have?
The Cnh Steyr CVT 6200 delivers 197 hp.
How much does the Cnh Steyr CVT 6200 weigh?
The unladen weight is 7,200 kg.
What engine does the Cnh Steyr CVT 6200 have?
6 cylinders, 6,728 cm³ displacement, Diesel / Biodiesel.
How fast does the Cnh Steyr CVT 6200 go?
Top speed is 40 km/h.
What are the dimensions of the Cnh Steyr CVT 6200?
5,017 mm × 2,682 mm × 3,090 mm.
When was the Cnh Steyr CVT 6200 built?
Production years: 2009–2012.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 17 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
