CLAAS Axos 320
Built: 2008 · Series: Axos
More machines from model year 2008
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
CLAAS Axos – Entry-Level Series Since 2008, with Perkins Four-Cylinder Engines, 55 to 76 kW/75 to 102 hp and Operating Weight from 3,650 to 4,400 kg
CLAAS introduced the Axos in 2008 as a compact entry-level series positioned below the Arion; in the register, the production span of recorded models extends to the current Axos 3 model years. Engine output ranges from 55 to 76 kW, with models rated in horsepower spanning 75 to 102 hp, using four-cylinder engines with displacement from 3,595 to 4,400 cm³.
Read on 3 more paragraphs
Recorded operating weight runs from 3,650 to 4,400 kg, wheelbase of the recorded models is 2,489 mm, and top speed is 40 km/h. Within the Axos family, CLAAS distinguishes equipment lines with suffixes such as C, CL and CX, denoting different gearbox and cab variants.
Within the CLAAS range, the Axos is positioned as a simple, robust tractor for smaller and medium farms and as a second tractor on larger operations. Buyers of a used Axos should check the gearbox variant, as simple shuttle transmissions and powershift versions were offered in parallel.
With rated outputs from 55 to 76 kW, the Axos falls within ISO 730 Category II for the rear three-point hitch, with a standard dual-speed power take-off at 540 and 1,000 revolutions per minute. Perkins, the British engine maker supplying the series' four-cylinder diesel engines, is now part of the Caterpillar group and continues to produce engines and spare parts for these model years.
Sources: SpecCodex register, model data: CLAAS Axos, CLAAS
Technical data
Engine
| Power | 87 hp (64 kW)correct |
|---|---|
| Displacement | 4,400 cm³correct |
Dimensions and weights
| Length | 4,181 mmcorrect |
|---|---|
| Height | 2,660 mmcorrect |
| Wheelbase | 2,489 mmcorrect |
| Unladen weight | 3,730 kgcorrect |
Drivetrain and chassis
| Front tyres | 13.6R24correct |
|---|---|
| Rear tyres | 16.9R34correct |
| Top speed | 40 km/hcorrect |
Working data
| Fuel tank capacity | 145 lcorrect |
|---|
Origin and approval
| Version | AXOS 320 Ccorrect |
|---|
Where this model stands
Power-to-weight ratio: 17.2 kW/t (64 kW / 3.7 t)
Power class: Universal (40–100 hp)
Stronger than 59% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the CLAAS Axos 320 have?
The CLAAS Axos 320 delivers 87 hp.
How much does the CLAAS Axos 320 weigh?
The unladen weight is 3,730 kg.
What engine does the CLAAS Axos 320 have?
4,400 cm³ displacement.
How fast does the CLAAS Axos 320 go?
Top speed is 40 km/h.
What are the dimensions of the CLAAS Axos 320?
4,181 mm × 2,660 mm.
When was the CLAAS Axos 320 built?
Production years: 2008.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
