Chrysler VOYAGER 2.5CRD VAN
Built: 2005-2009 · Series: VOYAGER
More machines from model year 2005
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Chrysler VOYAGER – collective page of the large van from Graz: 2.5 TD/CRD diesels and 3.3/3.8 V6 petrol, SE/LE trim, 2.4 to 3.8 litre displacement
This page gathers the Chrysler Voyager and Grand Voyager, the large-van programme Chrysler sold in Europe under its own name from 1988, after Plymouth and Dodge had offered the model in North America since 1984. From 1995/1996 the European Voyager was built in Graz, Austria, at the Eurostar joint plant with Steyr-Daimler-Puch. The type designation gives displacement and drivetrain – 2.5 TD and 2.5 CRD for the four-cylinder turbodiesels, 3.3I and 3.8I for the V6 petrol engines – SE and LE mark the equipment lines, and High Roof the raised roof of the commercial version.
Read on 3 more paragraphs
The register lists here 50 versions with displacements from 2,429 to 3,778 cm³ from four- to six-cylinders, unladen weights from 1,440 to 1,984 kg against gross weights of 2,210 to 2,560 kg and widths from 1,760 to 2,000 mm; outputs are recorded for a handful of entries at 85 to 110 kW, lengths at 4,730 to 4,900 mm.
The Voyager is regarded as a pioneer of the modern large van and competed in Europe with the Renault Espace and VW Sharan; the models on this page, registered as High Roof or Commercial versions, were used above all commercially as courier and tradesman vehicles.
On used examples, the CRD engines from VM Motori call for checking the timing chain and turbocharger, the V6 petrol engines the cooling system, and the body for rust at the sliding-door tracks and floor pan; parts supply runs through the Stellantis network, though it thins out on older models.
Sources: SpecCodex register, model data: Chrysler VOYAGER, Stellantis (Konzern)
Technical data
Engine
| Cylinders | 4correct |
|---|---|
| Displacement | 2,499 cm³correct |
Dimensions and weights
| Width | 2,000 mmcorrect |
|---|---|
| Wheelbase | 2,880 mmcorrect |
| Unladen weight | 1,810 kgcorrect |
| Gross vehicle weight | 2,555 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|
Frequently asked questions
How much does the Chrysler VOYAGER 2.5CRD VAN weigh?
The unladen weight is 1,810 kg.
What is the gross vehicle weight of the Chrysler VOYAGER 2.5CRD VAN?
2,555 kg.
What engine does the Chrysler VOYAGER 2.5CRD VAN have?
4 cylinders, 2,499 cm³ displacement.
When was the Chrysler VOYAGER 2.5CRD VAN built?
Production years: 2005-2009.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 9 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
