Caterpillar Challenger 45
Built: 1994 · Series: Challenger
More machines from model year 1994
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Caterpillar Challenger — Cat's rubber-track tractor, now built by AGCO
The Challenger line covers 15 models in the database from 149 to 310 kW, consistently with six-cylinder engines — a power class that clearly points to large farm tractors rather than construction machines: the Challenger was Caterpillar's entry into rubber-tracked agricultural tractors.
Read on 4 more paragraphs
Cat launched the line in 1986 with the Challenger 65, fitted with its own Mobile-Trac System — sprung rubber tracks combining the flotation and pulling power of steel tracks with tyre-like road manners. In 2002 Caterpillar sold the entire Challenger tractor business to AGCO, licensing the name and livery — since then the line has continued under the Challenger brand at AGCO, while Caterpillar itself refocused on construction equipment.
Challenger tractors were, and still are, used mainly in large-scale row-crop farming, where the soil-friendliness of rubber tracks combined with high drawbar pull is the deciding factor.
For an older, originally Cat-built Challenger (pre-2002), the condition of the rubber track undercarriage and the suspension components matters most.
In short: reading "Caterpillar Challenger" historically means buying a farm tractor, not a construction machine — and depending on the build year, either an original Cat product or a later AGCO product under Cat licence.
Sources: SpecCodex register, model data: Caterpillar Challenger, — Challenger Tractor (Wikipedia), — Why did Caterpillar sell off the Challenger line? (The Western Producer)
Technical data
Engine
| Engine make | Caterpillarcorrect |
|---|---|
| Engine model | 3,116correct |
| Fuel | dieselcorrect |
| Power | 200 hp (149 kW)correct |
| Rated speed | 2,100 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 403 cu incorrect |
| Bore | 4.13 in (104.9 mm)correct |
| Stroke | 5.0 in (127 mm)correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Turning circle | 0correct |
|---|
Drivetrain and chassis
| Drive | tracked undercarriagecorrect |
|---|---|
| Gearbox | powershift transmission with power shuttlecorrect |
| Forward gears | 16correct |
| Reverse gears | 9correct |
Working data
| Lifting capacity | 12, 500 lbs; 15, 000 lbs (opt)correct |
|---|---|
| Fuel tank capacity | 125 galcorrect |
Origin and approval
| Plant | USAcorrect |
|---|
Other data
| Linkage category | Cat II, Cat IIIN, Cat IIIcorrect |
|---|---|
| PTO speed | 1,000correct |
More machines with this engine (Caterpillar 3116, 12)
Frequently asked questions
How much power does the Caterpillar Challenger 45 have?
The Caterpillar Challenger 45 delivers 200 hp.
What engine does the Caterpillar Challenger 45 have?
6 cylinders, Diesel.
When was the Caterpillar Challenger 45 built?
Production years: 1994.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 23 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
