Case New Holland TD 90 D (A) – specifications
Built: 2004–2008 · Series: TDD-Baureihe
The TDD series from Case New Holland includes the TD 90 D (A). Production: 2004–2008. The engine delivers 89 hp (65.5 kW), has 4 cylinders, with a displacement of 3,908 cm³. Torque is 325 Nm. Rated speed is 2,500 rpm. The machine is 4,109 mm long, 1,808 mm wide and 2,602 mm high. The unladen weight is 3,135 kg. The wheelbase measures 2,305 mm. Ground clearance is 390 mm. Top speed is 30 km/h. Transmission: 12 V/12 R, 20 V/12 R and 12 V/4 R. The engine is water-cooled. Tyres: front 9.00-16 SL (A: 12.4 R 24 AS), rear 18.4 R 34 AS (A: 18.4 R 30 AS). The fuel is diesel. The bore measures 104 mm. The stroke is 115 mm. The compression ratio is 18.5:1. Maximum torque is reached at 1,350 rpm. Construction: unit construction (no separate frame). The TDD-Baureihe series covers 7 models. Rated output within it ranges from 59 to 98 hp; the TD 90 D (A) sits in the upper part of that range with 89 hp. Its immediate neighbours are the TD 85 D (A) below it with 84 hp and the TD 95 D (A) above it with 98 hp. Unladen weight within it ranges from 2,566 to 3,165 kg; here the TD 90 D (A) sits at the top of that range with 3,135 kg. 84 Case New Holland models across 17 series are on record.
Data for the version built 2004–2008 · Data origin: Reference work (Wikipedia/Wikibooks) · sources
More machines from model year 2004
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
New Holland TD-D series (2000s) – the simple utility tractor from Ankara and New Delhi: TD 60 D to TD 95 D, the number as hp class, D as version of the range, A for four-wheel drive
The TD range is New Holland's tractor for farms looking for technology without electronics: a simple utility class based on the Fiat 66 and 86 ranges, built outside Western Europe – at Türk Traktör in Ankara, the CNH joint venture with Koç, and in New Delhi – and sold in Eastern Europe, Turkey, Africa and South Asia, in Western Europe as the price entry. The type logic: TD marks the range, the number the hp class – TD 60 about 60 hp, TD 75 75 hp, TD 95 about 95 hp – D the version of this generation by factory logic, A four-wheel drive; the successors are called TD5 and TD5.x. The engines are the Fiat 8000 series in its late form: the three-cylinder of 2.9 litres in the TD 60 and TD 70, the four-cylinder of 3.9 litres in the models from the TD 75 upward, at 2,500 rpm, with mechanical in-line injection pump.
Read on 3 more paragraphs
The register lists 7 versions with 43.4 to 72.1 kW from three- and four-cylinders of 2,931 to 3,908 cm³, torque from 181 to 325 Nm, unladen weights from 2,566 to 3,165 kg, lengths from 3,630 to 4,192 mm, widths from 1,799 to 1,975 mm and heights from 2,472 to 2,652 mm.
The TD is one of the best-selling tractors of its class in Poland, Romania, Turkey and North Africa; its argument is repair-friendliness without a diagnostic tool.
On used tractors, operating hours, clutch and shuttle (Synchro Shuttle), four-wheel-drive clutch on A models, injection pump, hydraulics and sheet metal count; parts run through CNH and are widely available thanks to the 8000 series.
Sources: SpecCodex register, model data: New Holland TD-D-Baureihe, New Holland Agriculture (manufacturer)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 89 hp (65.5 kW)correct |
| Rated speed | 2,500 rpmcorrect |
| Torque | 325 Nmcorrect |
| Speed at max. torque | 1,350 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,908 cm³correct |
| Bore | 104 mmcorrect |
| Stroke | 115 mmcorrect |
| Compression ratio | 18.5correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,109 mmcorrect |
|---|---|
| Width | 1,808 mmcorrect |
| Height | 2,602 mmcorrect |
| Wheelbase | 2,305 mmcorrect |
| Ground clearance | 390 mmcorrect |
| Unladen weight | 3,135 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 12 V/12 R, 20 V/12 R and 12 V/4 Rcorrect |
| Front tyres | 9.00-16 SL (A: 12.4 R 24 AS)correct |
| Rear tyres | 18.4 R 34 AS (A: 18.4 R 30 AS)correct |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Frequently asked questions
Where this model stands
Power-to-weight ratio: 20.9 kW/t (66 kW / 3.1 t)
Power class: Universal (40–100 hp)
Stronger than 60% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
