Case CX700

Series: Case Hydraulic Excavator

Source: https://www.flickr.com/photos/alexprevot/51440217183/

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Case CX700 belongs to the Case Hydraulic Excavator series. The engine delivers 316.9 kW, has 6 cylinders, with a displacement of 15,682.4 cm³. Torque is 1,979.5 Nm. Rated speed is 1,800 rpm. The unladen weight is 69,535.7 kg. The tank holds 900.9 litres. Maximum torque is reached at 1,500 rpm. The pump delivers 400.1 l/min. The hydraulic tank holds 651.1 litres. Working pressure is 314 bar. The cooling system holds 112 litres. The oil fill is 51.9 litres. The electrical system runs on 24 V. The engine fitted is the AH-6WG1X. Tier III certified. The Case Hydraulic Excavator series covers 56 models. Rated output within it ranges from 65.6 to 396.7 kW; the CX700 sits in the upper part of that range with 316.9 kW. Its immediate neighbours are the CX470B below it with 270 kW and the CX750D above it with 343 kW. 620 Case models across 22 series are on record. The model is listed under Excavators & compaction. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine modelAH-6WG1X, Tier III certifiedcorrect
Power316.9 kWcorrect
Rated speed1,800 rpmcorrect
Torque1,979.5correct
Speed at max. torque1,500 rpmcorrect
Cylinders6correct
Displacement15,682.4 cm³correct
Aspirationturbochargedcorrect
Coolant capacity112 lcorrect
Engine oil capacity51.9 lcorrect

Dimensions and weights

Unladen weight69,535.7 kgcorrect

Drivetrain and chassis

System voltage24 Vcorrect

Working data

Pump flow400.1 l/mincorrect
Hydraulic oil capacity651.1 lcorrect
Hydraulic pressure314 barcorrect
Fuel tank capacity900.9 lcorrect

Other data

Height3,785.6correct

Where this model stands

Power-to-weight ratio: 4.6 kW/t (317 kW / 69.5 t)

Stronger than 92% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Case CX700 have?

The Case CX700 delivers 317 kW.

How much does the Case CX700 weigh?

The unladen weight is 69,536 kg.

What engine does the Case CX700 have?

6 cylinders, 15,682 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
