Case 9030B
Series: Case Hydraulic Excavator
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Technical data
Engine
| Engine model | 6T-590correct |
|---|---|
| Power | 97.7 kWcorrect |
| Rated speed | 2,000 rpmcorrect |
| Torque | 576.2correct |
| Speed at max. torque | 1,500 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 5,883 cm³correct |
| Aspiration | turbochargedcorrect |
| Coolant capacity | 25.7 lcorrect |
| Engine oil capacity | 16.3 lcorrect |
Dimensions and weights
| Ground clearance | 457.2correct |
|---|---|
| Unladen weight | 20,203 kgcorrect |
Drivetrain and chassis
| System voltage | 24 Vcorrect |
|---|
Working data
| Pump flow | 194.2 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 200.2 lcorrect |
| Hydraulic pressure | 314 barcorrect |
| Fuel tank capacity | 310.4 lcorrect |
Other data
| Height | 2,932.2correct |
|---|
Where this model stands
Power-to-weight ratio: 4.8 kW/t (98 kW / 20.2 t)
Stronger than 40% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Case 9030B have?
The Case 9030B delivers 97.7 kW.
How much does the Case 9030B weigh?
The unladen weight is 20,203 kg.
What engine does the Case 9030B have?
6 cylinders, 5,883 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
