Case 680L

Series: Case Loader Backhoe

Source: https://www.truck1.eu/trucks/refrigerator-trucks

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Case Loader Backhoe series from Case includes the 680L. The engine delivers 102.4 hp (67.1 kW), has 6 cylinders, with a displacement of 5,883 cm³. The engine comes from Case. Rated speed is 2,200 rpm. The wheelbase measures 2,212.8 mm. Ground clearance is 356.6 mm. The tank holds 163.2 litres. The gearbox has 3 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,200 rpm. The pump delivers 70.8 l/min. The hydraulic tank holds 54.1 litres. Working pressure is 137.9 bar. The cooling system holds 25.7 litres. The electrical system runs on 12 V. The engine fitted is the 6-590. The Case Loader Backhoe series covers 38 models. Rated output within it ranges from 42.1 to 125.7 hp; the 680L sits in the upper part of that range with 102.4 hp. Its immediate neighbours are the 590 Super M below it with 100.4 hp and the 695 4x4x4 above it with 107.8 hp. 620 Case models across 22 series are on record. The model is listed under Wheel loaders. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine makeCasecorrect
Engine model6-590correct
Power102.4 hp (67.1 kW)correct
Rated speed2,200 rpmcorrect
Speed at max. torque1,200 rpmcorrect
Cylinders6correct
Displacement5,883 cm³correct
Coolant capacity25.7 lcorrect

Dimensions and weights

Wheelbase2,212.8correct
Ground clearance356.6correct

Drivetrain and chassis

Gearbox typePower shiftcorrect
Forward gears3correct
Reverse gears3correct
System voltage12 Vcorrect

Working data

Pump flow70.8 l/mincorrect
Hydraulic oil capacity54.1 lcorrect
Hydraulic pressure137.9correct
Fuel tank capacity163.2 lcorrect

Frequently asked questions

How much power does the Case 680L have?

The Case 680L delivers 102 hp.

What engine does the Case 680L have?

6 cylinders, 5,883 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 19 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
