Case 680H

Series: Case Loader Backhoe

Source: https://www.landwirt.com/baumaschinen/radlader/case

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the 680H, Case offers a model from the Case Loader Backhoe series. The engine delivers 88.2 hp (59.7 kW), has 4 cylinders, with a displacement of 5,506.1 cm³. Rated speed is 2,200 rpm. The wheelbase measures 2,212.8 mm. The tank holds 124.9 litres. Maximum torque is reached at 1,500 rpm. The pump delivers 98.4 l/min. The hydraulic tank holds 52.2 litres. Working pressure is 175.8 bar. The cooling system holds 34.4 litres. The electrical system runs on 24 V. The engine fitted is the A336BD. The Case Loader Backhoe series covers 38 models. Rated output within it ranges from 42.1 to 125.7 hp; the 680H sits in the middle of that range with 88.2 hp. Its immediate neighbours are the 580M TURBO below it with 86.2 hp and the 680G above it with 89.2 hp. 620 Case models across 22 series are on record. The model is listed under Wheel loaders. 14 verified figures from 1 source are on file.

Technical data

Engine

Engine modelA336BDcorrect
Power88.2 hp (59.7 kW)correct
Rated speed2,200 rpmcorrect
Speed at max. torque1,500 rpmcorrect
Cylinders4correct
Displacement5,506.1 cm³correct
Coolant capacity34.4 lcorrect

Dimensions and weights

Wheelbase2,212.8correct

Drivetrain and chassis

System voltage24 Vcorrect

Working data

Pump flow98.4 l/mincorrect
Hydraulic oil capacity52.2 lcorrect
Hydraulic pressure175.8correct
Fuel tank capacity124.9 lcorrect

Frequently asked questions

How much power does the Case 680H have?

The Case 680H delivers 88.2 hp.

What engine does the Case 680H have?

4 cylinders, 5,506 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 14 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
