Case 580SL

Series: Case Loader Backhoe

Source: https://www.kleinanzeigen.de/s-anzeige/case-580-f-baggerlade

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Case Loader Backhoe series from Case includes the 580SL. The engine delivers 92.3 hp (64.1 kW), has 4 cylinders, with a displacement of 3,916.5 cm³. The engine comes from Case. Rated speed is 2,200 rpm. The wheelbase measures 2,133.6 mm. Ground clearance is 381 mm. The tank holds 118.9 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 104.1 l/min. The hydraulic tank holds 124.9 litres. Working pressure is 172.4 bar. The cooling system holds 16.7 litres. The electrical system runs on 12 V. The engine fitted is the 4T-390. The Case Loader Backhoe series covers 38 models. Rated output within it ranges from 42.1 to 125.7 hp; the 580SL sits in the upper part of that range with 92.3 hp. Its immediate neighbours are the 580N below it with 91.1 hp and the 580 Super M above it with 96.3 hp. 620 Case models across 22 series are on record. The model is listed under Wheel loaders. 20 verified figures from 1 source are on file.

Technical data

Engine

Engine makeCasecorrect
Engine model4T-390correct
Power92.3 hp (64.1 kW)correct
Rated speed2,200 rpmcorrect
Speed at max. torque1,400 rpmcorrect
Cylinders4correct
Displacement3,916.5 cm³correct
Aspirationturbochargedcorrect
Coolant capacity16.7 lcorrect

Dimensions and weights

Wheelbase2,133.6correct
Ground clearance381correct

Drivetrain and chassis

Gearbox typeFully synchromesh gearbox 4-speed forward reverse shuttlecorrect
Forward gears4correct
Reverse gears4correct
System voltage12 Vcorrect

Working data

Pump flow104.1 l/mincorrect
Hydraulic oil capacity124.9 lcorrect
Hydraulic pressure172.4correct
Fuel tank capacity118.9 lcorrect

Frequently asked questions

How much power does the Case 580SL have?

The Case 580SL delivers 92.3 hp.

What engine does the Case 580SL have?

4 cylinders, 3,916 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 20 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
