Case 335
Series: Case Articulated Dump Truck
The Case Articulated Dump Truck series from Case includes the 335. The engine delivers 415.7 hp (283.4 kW), has 6 cylinders, with a displacement of 12,896.6 cm³. Torque is 1,849.3 Nm. Rated speed is 2,100 rpm. The wheelbase measures 6,272.8 mm. Ground clearance is 542.5 mm. Top speed is 48 km/h. The tank holds 450.5 litres. The gearbox has 6 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,000 rpm. The hydraulic tank holds 300.2 litres. The oil fill is 34.8 litres. The electrical system runs on 24 V. The engine fitted is the 13F3B. Tyre size: tubeless 26,5xR25xADN. The Case Articulated Dump Truck series covers 8 models. Rated output within it ranges from 263.6 to 462.3 hp; the 335 sits in the upper part of that range with 415.7 hp. Its immediate neighbours are the 330B below it with 353.8 hp and the 340 above it with 462.3 hp. 620 Case models across 22 series are on record. The model is listed under Mining equipment. 22 verified figures from 1 source are on file.
Technical data
Engine
| Engine model | 13F3Bcorrect |
|---|---|
| Power | 415.7 hp (283.4 kW)correct |
| Rated speed | 2,100 rpmcorrect |
| Torque | 1,849.3correct |
| Speed at max. torque | 1,000 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 12,896.6 cm³correct |
| Aspiration | Turbocharged with Aftercoolercorrect |
| Engine oil capacity | 34.8 lcorrect |
Dimensions and weights
| Length | 10,780.8correct |
|---|---|
| Width | 3,191.3correct |
| Wheelbase | 6,272.8correct |
| Ground clearance | 542.5correct |
Drivetrain and chassis
| Gearbox type | Power Shiftcorrect |
|---|---|
| Forward gears | 6correct |
| Reverse gears | 3correct |
| Tyre size | tubeless 26.5xR25xADNcorrect |
| Top speed | 48 km/hcorrect |
| System voltage | 24 Vcorrect |
Working data
| Hydraulic oil capacity | 300.2 lcorrect |
|---|---|
| Fuel tank capacity | 450.5 lcorrect |
Frequently asked questions
How much power does the Case 335 have?
The Case 335 delivers 416 hp.
What engine does the Case 335 have?
6 cylinders, 12,897 cm³ displacement.
How fast does the Case 335 go?
Top speed is 48 km/h.
What are the dimensions of the Case 335?
10,781 mm × 3,191 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
