Case 330B

Series: Case Articulated Dump Truck

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 330B from Case is part of the Case Articulated Dump Truck series. The engine delivers 353.8 hp (249.1 kW), has 6 cylinders, with a displacement of 1,050.4 cm³. Torque is 1,650 Nm. Rated speed is 1,800 rpm. The machine is 10,034 mm long. The wheelbase measures 5,910.1 mm. Ground clearance is 469.4 mm. Top speed is 46.3 km/h. The tank holds 378.5 litres. The gearbox has 6 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,140 rpm. The hydraulic tank holds 219.9 litres. The oil fill is 30.3 litres. The electrical system runs on 24 V. The engine fitted is the Cat 3306TA. Tyre size: Tubeless 23,5 R25. The Case Articulated Dump Truck series covers 8 models. Rated output within it ranges from 263.6 to 462.3 hp; the 330B sits in the middle of that range with 353.8 hp. Its immediate neighbours are the 330 below it with 319.4 hp and the 335 above it with 415.7 hp. 620 Case models across 22 series are on record. The model is listed under Mining equipment. 22 verified figures from 1 source are on file.

Technical data

Engine

Engine model	Cat 3306TAcorrect
Power	353.8 hp (249.1 kW)correct
Rated speed	1,800 rpmcorrect
Torque	1,650correct
Speed at max. torque	1,140 rpmcorrect
Cylinders	6correct
Displacement	1,050.4 cm³correct
Aspiration	Turbocharged with Aftercoolercorrect
Engine oil capacity	30.3 lcorrect

Dimensions and weights

Length	10,034correct
Width	2,971.8correct
Wheelbase	5,910.1correct
Ground clearance	469.4correct

Drivetrain and chassis

Gearbox type	powershift transmissioncorrect
Forward gears	6correct
Reverse gears	3correct
Tyre size	Tubeless 23.5 R25correct
Top speed	46.3 km/hcorrect
System voltage	24 Vcorrect

Working data

Hydraulic oil capacity	219.9 lcorrect
Fuel tank capacity	378.5 lcorrect

Frequently asked questions

How much power does the Case 330B have?

The Case 330B delivers 354 hp.

What engine does the Case 330B have?

6 cylinders, 1,050 cm³ displacement.

How fast does the Case 330B go?

Top speed is 46.3 km/h.

What are the dimensions of the Case 330B?

10,034 mm × 2,972 mm.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
