Case 325
Series: Case Articulated Dump Truck
The Case 325 belongs to the Case Articulated Dump Truck series. The engine delivers 263.6 hp (184.9 kW), has 6 cylinders, with a displacement of 8,291.9 cm³. Torque is 1,122.6 Nm. Rated speed is 2,200 rpm. The machine is 2,795 mm wide. The wheelbase measures 6,032 mm. Ground clearance is 521.2 mm. Top speed is 47.6 km/h. The tank holds 325.5 litres. The gearbox has 6 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,400 rpm. The hydraulic tank holds 199.9 litres. The oil fill is 22 litres. The electrical system runs on 24 V. The engine fitted is the 6CTAA-8,3. Tyre size: tubeless 23,5xR25. The Case Articulated Dump Truck series covers 8 models. Rated output within it ranges from 263.6 to 462.3 hp; the 325 sits at the bottom of that range with 263.6 hp. Its immediate neighbours are the 327B above it with 319.4 hp. 620 Case models across 22 series are on record. The model is listed under Mining equipment. 22 verified figures from 1 source are on file.
Technical data
Engine
| Engine model | 6CTAA-8.3correct |
|---|---|
| Power | 263.6 hp (184.9 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Torque | 1,122.6correct |
| Speed at max. torque | 1,400 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 8,291.9 cm³correct |
| Aspiration | Turbocharged and Aftercooledcorrect |
| Engine oil capacity | 22 lcorrect |
Dimensions and weights
| Length | 9,829.8correct |
|---|---|
| Width | 2,795correct |
| Wheelbase | 6,032correct |
| Ground clearance | 521.2correct |
Drivetrain and chassis
| Gearbox type | Power Shiftcorrect |
|---|---|
| Forward gears | 6correct |
| Reverse gears | 3correct |
| Tyre size | tubeless 23.5xR25correct |
| Top speed | 47.6 km/hcorrect |
| System voltage | 24 Vcorrect |
Working data
| Hydraulic oil capacity | 199.9 lcorrect |
|---|---|
| Fuel tank capacity | 325.5 lcorrect |
Frequently asked questions
How much power does the Case 325 have?
The Case 325 delivers 264 hp.
What engine does the Case 325 have?
6 cylinders, 8,292 cm³ displacement.
How fast does the Case 325 go?
Top speed is 47.6 km/h.
What are the dimensions of the Case 325?
9,830 mm × 2,795 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
