Case 327B

Series: Case Articulated Dump Truck

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Case 327B is a model in the Case Articulated Dump Truck series. The engine delivers 319.4 hp (223.7 kW), has 6 cylinders, with a displacement of 10,307.5 cm³. Torque is 1,450 Nm. Rated speed is 2,100 rpm. The machine is 10,034 mm long. The wheelbase measures 5,910.1 mm. Ground clearance is 469.4 mm. Top speed is 46.3 km/h. The tank holds 378.5 litres. The gearbox has 6 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,400 rpm. The hydraulic tank holds 219.9 litres. The oil fill is 30.3 litres. The electrical system runs on 24 V. The engine fitted is the Family IV 10 liter Tier III certified. Tyre size: Tubeless 23,5 R25. The Case Articulated Dump Truck series covers 8 models. Rated output within it ranges from 263.6 to 462.3 hp; the 327B sits in the lower part of that range with 319.4 hp. Its immediate neighbours are the 325 below it with 263.6 hp and the 330B above it with 353.8 hp. 620 Case models across 22 series are on record. The model is listed under Mining equipment. 22 verified figures from 1 source are on file.

Technical data

Engine

Engine modelFamily IV 10 liter Tier III certifiedcorrect
Power319.4 hp (223.7 kW)correct
Rated speed2,100 rpmcorrect
Torque1,450correct
Speed at max. torque1,400 rpmcorrect
Cylinders6correct
Displacement10,307.5 cm³correct
AspirationTurbocharged with Aftercoolercorrect
Engine oil capacity30.3 lcorrect

Dimensions and weights

Length10,034correct
Width2,971.8correct
Wheelbase5,910.1correct
Ground clearance469.4correct

Drivetrain and chassis

Gearbox typepowershift transmissioncorrect
Forward gears6correct
Reverse gears3correct
Tyre sizeTubeless 23.5 R25correct
Top speed46.3 km/hcorrect
System voltage24 Vcorrect

Working data

Hydraulic oil capacity219.9 lcorrect
Fuel tank capacity378.5 lcorrect

Frequently asked questions

How much power does the Case 327B have?

The Case 327B delivers 319 hp.

What engine does the Case 327B have?

6 cylinders, 10,308 cm³ displacement.

How fast does the Case 327B go?

Top speed is 46.3 km/h.

What are the dimensions of the Case 327B?

10,034 mm × 2,972 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
