Broshuis E-2130 V
Built: 1982-1986 · Series: E-2130
More machines from model year 1982
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Broshuis E-2130 – Dutch low-loader semi-trailers from Kampen with a gross weight rating of 34,000 to 43,000 kg: six versions, 13,090 to 13,780 mm length
The E-2130 range from Broshuis of Kampen gathers low-loader semi-trailers in several versions, from the E-2130 V through the E-2130/27 to the E-2130 K; the 2130 designation stays constant across all variants, while the LNS, V and K suffixes and the number 27 mark different axle or frame configurations of the same base type. With gross weight ratings of 34 to 43 tonnes, the whole range falls into class O4, the heavy semi-trailers above 10 tonnes.
Read on 3 more paragraphs
The register lists here 6 versions with unladen weights from 6,800 to 25,600 kg and gross weight ratings from 34,000 to 43,000 kg. Lengths range from 13,090 to 13,780 mm, widths from 2,500 to 2,590 mm.
At lengths around 13 m and gross weights up to 43 tonnes, the E-2130 range counts among the long low-loaders of European heavy haulage, carrying construction machinery, agricultural equipment or industrial plant where a low loading height matters for tall or bulky goods. The wide unladen-weight span from 6.8 to 25.6 tonnes reflects very different frame and axle configurations within the same range.
On a used example, check the frame and chassis rails for cracks and deformation, the axle units and air suspension, the kingpin and wear plates of the mounting surface, and the brake system with its connections. On the long versions, also check the torsional stiffness of the frame, and on versions with a lowering deck the condition of the hydraulic cylinders; parts for axles and brake components come from the European commercial-vehicle parts trade.
Sources: SpecCodex register, model data: Broshuis E-2130
Technical data
Dimensions and weights
| Length | 13,100 mmcorrect |
|---|---|
| Width | 2,500 mmcorrect |
| Wheelbase | 9,120 mmcorrect |
| Unladen weight | 6,800 kgcorrect |
| Gross vehicle weight | 40,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Broshuis E-2130 V weigh?
The unladen weight is 6,800 kg.
What is the gross vehicle weight of the Broshuis E-2130 V?
40,000 kg.
Up to what speed is the Broshuis E-2130 V approved?
Approved up to 100 km/h.
What are the dimensions of the Broshuis E-2130 V?
13,100 mm × 2,500 mm.
When was the Broshuis E-2130 V built?
Production years: 1982-1986.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
