Brinkman & Havinga DE WOUDEN 001
Built: 2013 · Series: Other models
More machines from model year 2013
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Brinkman & Havinga De Wouden 001 – EU class O2 trailer: 3,500 kg gross vehicle weight, 960 kg unladen weight, 4,300 mm wheelbase, 2,220 mm wide, built 2013
With a gross vehicle weight of 3,500 kg, the Brinkman & Havinga De Wouden 001 falls into EU trailer class O2, trailers between 750 kg and 3.5 tonnes. Trailers in this class usually run on an overrun brake: when the towing vehicle brakes, the drawbar compresses slightly and mechanically applies the trailer's brakes, with no separate brake line to the towing vehicle.
Read on 3 more paragraphs
The Brinkman & Havinga De Wouden 001 was built in 2013 and has an unladen weight of 960 kg; against a gross vehicle weight of 3,500 kg, that leaves a payload of 2,540 kg. Width is 2,220 mm. The wheelbase is 4,300 mm, spread across 6 wheels. The permitted top speed is 100 km/h.
Trailers in this weight class are towed behind cars and light commercial vehicles for haulage and leisure use. The overrun brake needs no separate brake line to the towing vehicle, but does need a smooth-running, corrosion-free override mechanism and a working reversing lock so it does not brake unintentionally when reversing. The ratio of unladen weight to payload is within the usual range for this class.
When buying used, a trailer in this class lives or dies on the override mechanism: it must compress and extend smoothly, with no play or corrosion in the guide. The checklist should also cover brake cables, linings and the reversing lock, axle bearings, tyres and tread depth, the frame and floor for rust or damp, and the lighting. That also means checking the spare-parts supply for brakes and axles.
Sources: SpecCodex-Register: Kennwerte des Modells Brinkman & Havinga De Wouden 001
Technical data
Dimensions and weights
| Width | 2,220 mmcorrect |
|---|---|
| Wheelbase | 4,300 mmcorrect |
| Unladen weight | 960 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Brinkman & Havinga DE WOUDEN 001 weigh?
The unladen weight is 960 kg.
What is the gross vehicle weight of the Brinkman & Havinga DE WOUDEN 001?
3,500 kg.
Up to what speed is the Brinkman & Havinga DE WOUDEN 001 approved?
Approved up to 100 km/h.
When was the Brinkman & Havinga DE WOUDEN 001 built?
Production years: 2013.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
