Bonfiglioli BN80B4
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Bonfiglioli – other models: the collective page of MEPS-registered three-phase motors from the Bologna gearmotor maker outside the named ranges, frame sizes 80 to 200, 0.75 to 30 kW
This page gathers the Bonfiglioli three-phase motors the Australian energy-efficiency register could not assign to a named range. Bonfiglioli was founded in 1956 and is headquartered in Calderara di Reno near Bologna; the company is best known for gearmotors and drive technology, and supplies the three-phase motors listed here both as a standalone BN range and as a drive component for its gear programmes. Designations such as BN132MA4 or BN160L2 follow the scheme of range code BN, IEC frame size and a letter-digit code for length and pole count; the BE codes (BE132MB4, BE160L4) point to combinations with the ME gear range.
Read on 3 more paragraphs
The register lists here 44 versions with 0.75 to 30 kW, two- to six-pole, full-load efficiencies from 72.4 to 94.2% and at 75% load from 72.4 to 94.1%. Protection is mostly IP55, alongside combinations with IP54 and IP56; frame sizes run from 80 to 200. Italy and, in a few cases, combinations with Vietnam are recorded as manufacturing countries. Testing mostly followed the older AS/NZS 1359.5:2000 standard and the 2019 GEMS determination; only 7 of the 44 motors carry any documented High Efficiency classification at all, 5 at the 2018 level and one at the 2005 level.
Bonfiglioli is one of the large Italian drive-technology makers and competes with SEW-Eurodrive and Nord Drivesystems for applications in conveying technology, packaging machinery and mobile equipment; the motors on this collective page supplement the extensive BN range with older and rarer frame sizes.
When buying used, what matters is bearing condition and a checked insulation resistance of the winding, visible corrosion on the terminal box and fan cover, the condition of shaft and key, and a legible nameplate with range, frame size and efficiency class; since only a small share of the models carry a High Efficiency classification, inverter suitability should be checked case by case. Spares run through the Bonfiglioli service network.
Sources: SpecCodex register, model data: Bonfiglioli (weitere Modelle, MEPS-Registrierungen), Bonfiglioli (manufacturer)
Technical data
Engine
| Rated output | 0.75 kWcorrect |
|---|
Electrical data
| Rated voltage | 400 Vcorrect |
|---|---|
| Number of poles | 4correct |
| Protection class | IP55correct |
| Frame size | 80 M (foot)correct |
| Mounting (IEC 60034-7) | B5, B14correct |
| Efficiency at full load | 75 %correct |
| Efficiency at 75 % load | 74.5 %correct |
| Efficiency at half load | 68.71 %correct |
Origin and approval
| Country of manufacture | Italycorrect |
|---|
Other data
| Standard applied | AS/NZS 1359.5:2000 (Legacy)correct |
|---|---|
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
How much power does the Bonfiglioli BN80B4 have?
The Bonfiglioli BN80B4 delivers 0.8 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
