McCormick TTX230 – specifications
Built: 2010 · Series: Other models
Data for the version built 2010 · Data origin: Official register, Reference work (Wikipedia/Wikibooks) · sources
More machines from model year 2010
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The McCormick TTX230 is a tractor from the TTX series, launched in 2010. As a six-cylinder agricultural tractor, it is positioned in the upper power range of the series. The design, featuring a wheelbase of 2,873 mm and an overall length of 4,930 mm, forms the basis for stability during field operations. The empty weight of 7,975 kg ensures good traction, while the permissible gross weight of 12,500 kg defines the capacity for mounted implements and ballast weights.
The six-cylinder engine with a displacement of 6,728 cm³ delivers an output of 213 hp, equivalent to 154 kW. This power transmission enables the use of heavy plows or large seeders without the engine permanently reaching its performance limits. The transmission offers 32 forward gears, allowing for fine gradation of driving speed. This is particularly important in soil cultivation to provide optimal traction for various soil conditions and working speeds. The tank with a capacity of 350 l supports long working intervals without frequent refueling stops.
Within the series, the TTX230 occupies a position in the premium segment. It is suitable for farms working with large areas and heavy mounted implements. The combination of high weight and high power makes it suitable for demanding field work requiring high traction. The dimensions of 2,410 mm in width and 3,000 mm in height take into account road conditions and stability on terrain.
McCormick – from a Chicago Harvester Works to an Italian Tractor Maker
The McCormick Harvesting Machine Company built reapers in Chicago from 1847. In 1902 it merged into the newly formed International Harvester, alongside Deering and three smaller manufacturers. Tractors were first sold as McCormick-Deering, later simply as McCormick in Europe, while in the US they were renamed International. One example is the England-built diesel B-414 (1961–1966), successor to the B-275, with a larger bore and, from 1962, also a petrol version. In 1985, International Harvester sold its farm-equipment division; since 2007 McCormick has been built as an independent brand in Fabbrico, Italy. Listed in the register: the B-414 and XTX185.
Sources: Wikipedia – McCormick Tractors, Wikipedia – International Harvester, TractorData – International Harvester B-414
Technical data
Engine
| Power | 213 hp (154 kW)correct |
|---|---|
| Cylinders | 6correct |
| Displacement | 6,728 cm³correct |
Dimensions and weights
| Length | 4,930 mmcorrect |
|---|---|
| Width | 2,410 mmcorrect |
| Height | 3,000 mmcorrect |
| Wheelbase | 2,873 mmcorrect |
| Unladen weight | 7,975 kgcorrect |
| Gross vehicle weight | 12,500 kgcorrect |
Drivetrain and chassis
| Gears | 32correct |
|---|---|
| Forward gears | 32correct |
Working data
| Fuel tank capacity | 350 lcorrect |
|---|
Where this model stands
Power-to-weight ratio: 19.3 kW/t (154 kW / 8 t)
Power class: Heavy (> 180 hp)
Stronger than 92% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the McCormick TTX230 have?
The McCormick TTX230 delivers 213 hp.
How much does the McCormick TTX230 weigh?
The unladen weight is 7,975 kg.
What is the gross vehicle weight of the McCormick TTX230?
12,500 kg.
What engine does the McCormick TTX230 have?
6 cylinders, 6,728 cm³ displacement.
What are the dimensions of the McCormick TTX230?
4,930 mm × 2,410 mm × 3,000 mm.
When was the McCormick TTX230 built?
Production years: 2010.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 15 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Are you the manufacturer or a dealer of this machine? Check the data and add missing figures — we mark your correction as manufacturer or dealer information.
Check and complete the data →Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
